A-B 2711PT15C22D9P PanelView Plus 7 HMI

Allen‑Bradley 2711P‑T15C22D9P

PanelView Plus 7 Performance HMI (15" Touch)

Specifications

• Display: 15‑inch TFT color touchscreen, XGA (1024×768), 18‑bit color
• Touchscreen: 8‑wire analog resistive, 1 million+ actuations
• Processor: ARM Cortex‑A8, 1 GHz
• Memory: 512 MB RAM / 512 MB non‑volatile storage (~80 MB user app space)
• OS: Windows Embedded Compact 7
• Power: 24 VDC (18–30 VDC), max 50 W (2.1 A)
• Communication: 2× 10/100 Mbps Ethernet (RJ45, DLR support)
• Ports: 2× USB 2.0 host, 1× USB device, 1× SD card slot
• Backlight: White LED, 50,000 hours @ 40 °C (half‑brightness)
• Operating Temp: 0 °C to 55 °C
• Certifications: UL, cUL, CE, RoHS, CCC, IP65/NEMA 4X (front)
• Status: Active

Features

• Performance‑grade HMI: Dual Ethernet ports with DLR for redundant/ring networks
• High‑resolution 15" touch: Clear visualization for complex machine/process control
• Powerful processing: 1 GHz ARM Cortex‑A8 for fast graphics and data handling
• Flexible connectivity: Dual Ethernet, multiple USB, SD slot for expansion/backup
• Industrial durability: IP65 front panel, long‑life LED backlight, conformal coating option
• FactoryTalk compatible: Programming via FactoryTalk View ME v8.0+
