A-B 2711P-T15C22D9P PanelView Plus Touch Screen Operator Terminal

Allen-Bradley 2711P-T15C22D9P PanelView Plus 7 Performance Touch Screen Operator Terminal





Product Description

The Allen-Bradley 2711P-T15C22D9P is a PanelView Plus 7 Performance operator terminal designed for advanced Human-Machine Interface (HMI) applications. It features a 15-inch XGA TFT color touchscreen, dual Ethernet ports with Device Level Ring (DLR) support, and a powerful embedded computing platform for FactoryTalk View Machine Edition applications. The terminal provides reliable machine monitoring, process visualization, alarm management, and operator control in demanding industrial environments.

Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 2711P-T15C22D9P
• Series: PanelView Plus 7 Performance
• Type: Touch Screen Operator Terminal (HMI)
• Display Size: 15-inch TFT Color LCD
• Resolution: 1024 × 768 (XGA), 18-bit color
• Touchscreen: Analog resistive touch
• Memory: 512 MB RAM, 512 MB non-volatile memory
• Power Supply: 18–30 VDC (24 VDC nominal)
• Maximum Power Consumption: 50 W
• Communication Ports:
  • Dual 10/100 Ethernet (DLR capable)
  • USB Host ports
  • USB Device port
  • SD card slot
• Operating System: Windows 10 IoT Core (current production model)

Main Features

• 15-inch high-resolution color touchscreen
• PanelView Plus 7 Performance platform
• Dual Ethernet ports supporting Device Level Ring (DLR)
• FactoryTalk View ME compatible
• Integrated data logging, alarms, trends, and recipe management
• USB and SD card support for data backup and application transfer
• Rugged industrial design for continuous operation
• LED backlight with long service life

Applications

• Factory automation systems
• Machine control and monitoring
• Packaging equipment
• Automotive manufacturing
• Food and beverage processing
• Water and wastewater treatment
• Oil and gas facilities
• Pharmaceutical production
• Process automation systems

Advantages

• Large, high-resolution operator display
• Reliable industrial-grade touchscreen
• High-performance HMI platform
• Fast communication through dual Ethernet interfaces
• Easy integration with ControlLogix and CompactLogix PLCs
• Supports remote diagnostics and maintenance
• Long operating life with low maintenance requirements

Important Notes

• HMI operator terminal only
• Not a PLC CPU
• Not an I/O module
• Requires FactoryTalk View Machine Edition applications
• Designed for 24 VDC industrial control systems

Precautions

• Install in a properly sealed control panel according to environmental requirements.
• Verify the correct 24 VDC power supply before installation.
• Use compatible FactoryTalk View ME runtime software.
• Protect the touchscreen from excessive impact or sharp objects.
• Follow proper ESD precautions during installation and maintenance.
