A-B 2711P-T15C21D8S PanelView Plus 7 HMI

Allen‑Bradley 2711P‑T15C21D8S

PanelView Plus 7 Standard HMI (15" Touch)

Specifications

• Display: 15‑inch TFT color touchscreen, XGA (1024×768), 18‑bit color
• Memory: 512 MB RAM / 512 MB non‑volatile storageRockwell Automation
• OS: Windows CE 6.0
• Power: 24 VDC (18–30 VDC), max 50 W (2.1 A)
• Communication: 1× 10/100 Mbps Ethernet (RJ45, IEEE 1588)Rockwell Automation
• Ports: 2× USB 2.0, 1× SD card slot (for expansion/backup)
• Backlight: LED, 50,000 hours @ 40 °C (to half‑brightness)
• Operating Temp: 0 °C to 55 °C
• Certifications: UL, CE, CSA, CCC, EAC, RCMRockwell Automation
• Status: Active

Features

• High‑resolution 15" touchscreen: Clear visualization for complex machine/process control
• Integrated Ethernet: Seamless connection to ControlLogix/CompactLogix, supports real‑time communicationRockwell Automation
• Flexible data storage: USB/SD card for quick program backup/restore and data logging
• Remote monitoring: VNC server & FactoryTalk ViewPoint support for remote accessRockwell Automation
• Industrial durability: Rugged design for factory floor environments, long‑life LED backlight
• FactoryTalk compatible: Programming via FactoryTalk View Machine EditionRockwell Automation
