Allen‑Bradley 2711P-T10C22D9P PanelView Plus 7 Performance HMI

Basic Information

• Brand: Allen‑Bradley (Rockwell Automation)
• Model: 2711P-T10C22D9P
• Product Type: Industrial Touchscreen Operator Interface Terminal (HMI)

Model Code Interpretation

1. 2711P: PanelView Plus 7 HMI product series
2. T10: 10.4-inch color touchscreen display
3. C: Color TFT LCD screen
4. 22: Dual 10/100Mbps DLR Ethernet ports, built-in network switch
5. D: 24V DC power supply input
6. 9: Performance model with Windows 10 IoT Core system, expanded memory & peripheral interfaces
7. P: Standard front panel, NEMA 4/4X/12 rated

Core Technical Specifications

Display & Touch

• Screen Size: 10.4-inch TFT color LCD
• Resolution: 800 × 600 SVGA, 18-bit color depth
• Brightness: 300 nits LED backlight, 50,000-hour service life
• Input: Analog resistive touch screen, rated for 1 million touch operations

Memory & Storage

• RAM: 1 GB
• Built-in non-volatile storage: 2 GB
• Support external SD card expansion (1784-SDx series SD module)

Communication Interfaces

• 2 × 10/100 Base-T Ethernet ports with DLR device-level ring support
• 3 × USB 2.0 high-speed ports (2 Type-A host, 1 device port)
• 1 × RS-232 serial communication port

Electrical Parameters

• Power Input: 18–30V DC (nominal 24V DC)
• Max Power Consumption: 50W
• Operating Temperature: 0°C ~ +55°C
• Protection Grade: Front panel NEMA 12, 13, 4X; IP66

Software & System

• Operating System: Windows 10 IoT Core
• Programming Software: FactoryTalk View Machine Edition V2.6 or later
• Built-in functions: FTP server, VNC client/server, PDF viewer, ActiveX control support

Certifications

Product Advantages

1. Dual DLR Ethernet ports realize redundant industrial network topology, stable for factory automation
2. Windows 10 IoT Core system supports rich third-party software and file viewing functions
3. Abundant USB & serial ports for connecting scanners, printers, mouse, barcode readers
4. High industrial protection rating, suitable for dust, splash workshop environments
5. Perfect compatibility with Allen‑Bradley PLCs (Micro800, ControlLogix, CompactLogix)
6. Real-time battery-powered clock with accurate time stamping for production data logs

Application Scenarios

• Production line monitoring & operation control for packaging, food & beverage, machinery
• Pump, fan, HVAC and building automation control panels
• Automated assembly equipment, conveyor systems, robotic cell operator interface
• Hazardous light industrial Zone 2/22 environment monitoring
