A-B 2711P-T10C21D8S HMI Panel

Allen-Bradley 2711P-T10C21D8S PanelView Plus 7 HMI



6

The Allen-Bradley 2711P-T10C21D8S is a PanelView Plus 7 Performance series HMI (Human Machine Interface) used to monitor and control industrial automation systems. It allows operators to interact with PLC systems through graphical screens, alarms, trends, and control buttons.

It is part of the PanelView Plus 7 1000 series (10-inch touchscreen model).

Key Specifications

• Model: 2711P-T10C21D8S
• Brand: Allen-Bradley (Rockwell Automation)
• Series: PanelView Plus 7 Performance
• Display Size: 10.4 inch TFT color screen
• Resolution: 800 × 600 (SVGA)
• Input Type:
  • Resistive touchscreen
• Communication:
  • Ethernet (EtherNet/IP)
  • USB ports
  • Optional serial / other modules depending configuration
• Power Supply:
  • 18–30V DC (24V DC nominal)
• Software:
  • FactoryTalk View ME (Machine Edition)
• Enclosure Rating:
  • IP65 / NEMA 4X front panel

What it does (simple explanation)

PLC (ControlLogix / CompactLogix)
↓
EtherNet/IP communication
↓
PanelView Plus 7 HMI (2711P-T10C21D8S)
↓
Operator interface (screens, buttons, alarms)

It is used to:

• Display machine status
• Operate equipment (start/stop/set values)
• Show alarms and faults
• Monitor process data (temperature, pressure, speed)
• Provide graphical control interface

Main Functions

• Real-time machine monitoring
• Touchscreen operator control
• Alarm management and fault display
• Data trending and logging
• Recipe management (production settings)
• PLC tag communication via EtherNet/IP

Key Features

• 10-inch color touchscreen HMI
• High-performance PanelView Plus 7 platform
• FactoryTalk View ME compatibility
• Ethernet communication for PLC integration
• USB support for data transfer and peripherals
• Industrial rugged design (IP65 front)
• Supports multiple screens and complex animations

Applications

• Factory automation lines
• Packaging machinery
• Conveyor systems
• Pump and motor control systems
• Process industries (oil, water, chemical)
• CNC and OEM machine interfaces
