A-B 2711P-RP9DK PanelView Plus Logic Module

Allen-Bradley 2711P-RP9DK PanelView Plus 6 Logic Module



4

The Allen-Bradley 2711P-RP9DK is a PanelView Plus 6 logic module, used in PanelView Plus 700–1500 series operator terminals. It is the core computing module (CPU board) inside the HMI, running Windows CE-based runtime applications (FactoryTalk View ME).

Product Information

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 2711P-RP9DK
• Series: PanelView Plus 6 (700–1500 terminals)
• Type: Logic Module (HMI CPU board)
• Operating System: Windows CE 6.0 (embedded)
• Memory: 512 MB RAM / 512 MB Flash
• Power Input: 18–32 V DC
• Function: Runs HMI application (.MER files)

What it actually does

This module is responsible for:

• Running the HMI interface program
• Processing FactoryTalk View ME runtime (.MER files)
• Communicating with PLC systems (ControlLogix, CompactLogix, etc.)
• Handling screen logic, alarms, trends, recipes
• Managing Ethernet / serial communication with controllers

System Role (Simple)

PLC (e.g. 1756-L71)
→ communication network (EtherNet/IP)
→ 2711P-RP9DK logic module (this unit)
→ touchscreen display + operator interface

So it acts as the “industrial HMI computer inside the PanelView terminal.”

Key Features

• Embedded Windows CE 6.0 operating system
• High memory capacity (512 MB / 512 MB)
• Runs FactoryTalk View ME applications
• Supports multiple communication drivers (EtherNet/IP, DF1, etc.)
• Conformal-coated industrial design
• Designed for continuous 24/7 operation
• Plug-in replaceable logic module architecture

Typical Applications

• Machine operator interfaces (HMI panels)
• Production line monitoring systems
• Process visualization screens
• Alarm & event display systems
• Packaging, food, automotive, chemical plants
• Industrial SCADA terminal stations

Advantages

• Modular design (logic module can be replaced separately)
• Stable industrial Windows CE platform
• High compatibility with Rockwell PLC systems
• Easy maintenance (screen + logic separated)
• Long-term industrial reliability

Important Notes

• Not PLC CPU ❌
• Not I/O module ❌
• Not power supply ❌
• It is an HMI logic processor module (PanelView CPU) ✔

Precautions

• Must match correct PanelView Plus 6 terminal series (700–1500)
• Firmware compatibility is critical (MER runtime versions)
• Discontinued product (commonly sourced as spare part)
• Boot issues often caused by corrupted flash or firmware mismatch
• Not interchangeable with PanelView Plus 7 logic modules
