A-B 2711P-RP9D PanelView Plus Power Supply Module

Product Overview

The Allen-Bradley 2711P-RP9D is a PanelView Plus 6 700–1500 Logic Module with Windows CE 6.0, extended features, DC power input, and 512 MB RAM / 1 GB flash memory. It is a replacement logic module for compatible PanelView Plus 6 terminals. It is not a standalone power supply module.

Key Technical Specifications

Rockwell Automation lists the 2711P-RP9D as discontinued as of September 30, 2023, with engineering replacement status.

Advantages & Features

• Replacement logic module for compatible PanelView Plus 6 terminals
• 512 MB RAM + 1 GB flash for application and system storage
• Windows CE 6.0 operating environment
• Supports extended PanelView Plus 6 functionality
• DC-powered architecture
• Repairable/replaceable design
• Suitable for maintaining existing HMI installations

Applications

• HMI system maintenance
• Factory automation
• Machine control
• Production-line monitoring
• Process-control systems
• PanelView Plus 6 terminal replacement and repair
• Industrial equipment modernization

Important Notes

• 2711P-RP9D is a Logic Module, not an AC/DC power supply.
• It is designed for PanelView Plus 6 700–1500 terminals.
• For nonisolated DC PanelView terminals, Rockwell documentation specifies an appropriate 24 V DC SELV/PELV power supply.
• Verify the exact PanelView terminal model and series before replacement.
• Rockwell has discontinued this part, so confirm firmware, memory configuration, and compatibility before installation.
