A-B 2711P-RDT12H PanelView Plus Display Module

Allen-Bradley 2711P-RDT12H PanelView Plus Display Module

Product Description

The Allen-Bradley 2711P-RDT12H is a PanelView Plus High-Bright Display Module designed for PanelView Plus / PanelView Plus 6 1250 series operator terminals. It provides a 12.1-inch color TFT touch display with enhanced brightness, suitable for industrial environments where clear visibility is required.

Technical Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 2711P-RDT12H
• Product Type: PanelView Plus Display Module
• Series: PanelView Plus / PanelView Plus 6
• Display Size: 12.1 inch
• Display Type: Color TFT LCD
• Resolution: 800 × 600 pixels
• Touch Type: Analog resistive touch screen
• Brightness: 1000 cd/m² (High Bright)
• Input Voltage: 24 VDC nominal (18…32 VDC)
• Power Consumption: Max. 70 W (2.9 A @ 24 VDC)
• Backlight: Non-replaceable
• Protection Rating: IP65 front panel
• Mounting: Panel mount
• Compatible Terminal: PanelView Plus 1250 models
• External Storage: Supports CompactFlash up to 512 MB
• Dimensions (H×W×D): Approx. 282 × 363 × 74 mm
• Weight: Approx. 3.2 kg

Advantages & Features

• High-bright display improves visibility in bright industrial environments
• Large 12.1-inch TFT color screen for operator monitoring and control
• Resistive touch interface supports industrial operation
• Designed for PanelView Plus modular HMI systems
• Rugged construction for factory automation applications
• Supports replacement of damaged or aged display assemblies

Applications

• Industrial HMI operator panels
• Machine control systems
• Production line monitoring
• Factory automation equipment
• Process control systems
• PLC visualization interfaces

Notes / Precautions

• This is a display module only, not a complete HMI terminal
• Requires compatible PanelView Plus logic module and communication module
• Confirm model compatibility before replacement
• Check firmware and hardware series requirements
• Rockwell Automation has discontinued this display module; verify availability and replacement compatibility when upgrading systems.
