A-B 2711E-T10C6 HMI Panel

Allen-Bradley 2711E-T10C6 PanelView 1000e HMI Panel





The Allen-Bradley 2711E-T10C6 is a PanelView 1000e series industrial HMI (Human Machine Interface) used for machine visualization, alarm display, and operator control in PLC-based automation systems.

It is a legacy touchscreen HMI commonly used with PLC-5, SLC 500, and DH+/Remote I/O networks.

Key Specifications

• Model: 2711E-T10C6
• Series: PanelView 1000e (2711E series)
• Brand: Allen-Bradley (Rockwell Automation)
• Display: 10.4 inch color TFT screen
• Resolution: 640 × 480 (VGA)
• Input Type: Resistive touchscreen
• Power Supply: 85–264 VAC (wide range AC)
• Communication Ports:
  • Data Highway Plus (DH+)
  • Remote I/O (RIO)
• Memory: ~2.25 MB application memory
• Programming Software: PanelBuilder 1000e
• Mounting: Panel cut-out / clip mount
• Status: Discontinued / obsolete

What it does (simple explanation)

PLC System (PLC-5 / SLC / Control system)
↓
DH+ / Remote I/O network
↓
2711E-T10C6 HMI Panel
↓
Operator interface (screen + touch control)

It is used to:

• Display machine status
• Show alarms and fault messages
• Start/stop equipment
• Adjust process values
• Monitor PLC data in real time

Main Functions

• Industrial operator interface (HMI visualization)
• Alarm and event display
• Basic data entry via touchscreen
• PLC communication via DH+ / RIO
• Process monitoring and control
• Multi-screen application navigation

Key Features

• 10.4” color touchscreen display
• Supports DH+ and Remote I/O communication
• Built-in application memory for HMI projects
• Rugged industrial design (PanelView 1000e platform)
• Supports legacy Rockwell PLC systems
• High reliability for factory environments

Applications

• PLC-5 and SLC 500 systems
• Manufacturing machinery
• Conveyor systems
• Packaging equipment
• Process control plants
• Legacy automation system maintenance
