A-B 2711-T10C16 HMI Panel

Allen-Bradley 2711-T10C16 PanelView 1000 HMI





The Allen-Bradley 2711-T10C16 is a PanelView 1000 Series industrial HMI (Human Machine Interface) used to operate and monitor PLC-controlled systems. It provides a 10.4-inch color touchscreen display for machine visualization, alarms, and operator control in industrial automation systems.

This model belongs to the older PanelView Standard (2711 series) and is widely used in legacy Allen-Bradley PLC systems.

Key Specifications

• Model: 2711-T10C16
• Brand: Allen-Bradley (Rockwell Automation)
• Series: PanelView 1000 (Standard)
• Display Size: 10.4 inch TFT color screen
• Resolution: 640 × 480 pixels (VGA)
• Input Type: Touchscreen
• Power Supply: 85–264 VAC, 47–63 Hz
• Communication Ports:
  • RS-232 DF1 (PLC communication)
  • RS-232 printer port
• Memory: ~256 KB application memory
• Operating Temperature: 0–55°C
• Enclosure Rating: NEMA 4X / IP65 front panel (industrial protection)

(verified from industrial distribution and technical references)

What it does (Simple Explanation)

PLC Controller
↓
RS-232 DF1 communication
↓
2711-T10C16 HMI Panel
↓
Operator interface (screen + touch control)

It is used to:

• Display machine status
• Show alarms and faults
• Provide start/stop controls
• Adjust process parameters
• Monitor PLC data in real time

Main Functions

• Industrial machine visualization (HMI screens)
• Operator control of PLC systems
• Alarm display and event logging
• Basic process monitoring
• DF1 serial communication with Allen-Bradley PLCs
• Simple data entry via touchscreen

Key Features

• 10-inch color touchscreen interface
• Designed for legacy Allen-Bradley PLC systems
• RS-232 DF1 serial communication support
• Rugged industrial enclosure (NEMA 4X front)
• Field-replaceable backlight
• Stable operation in harsh environments
• CompactPanelView Standard architecture

Applications

• Legacy PLC control systems
• Manufacturing machines
• Packaging equipment
• Conveyor systems
• Pumps and basic process control
• Retrofit/maintenance of older Rockwell systems
