A-B 22D-E4P2H204 PowerFlex 40P Variable Frequency Drive

Product Overview

The Allen-Bradley 22D-E4P2H204 is a PowerFlex 40P adjustable frequency AC drive designed to control motor speed and performance in industrial applications. This 3 HP drive supports three-phase 600V AC input and features a plate-drive configuration for installation in compatible control panel assemblies.

Key Technical Specifications

Parameter	Specification
Brand	Allen-Bradley (A-B)
Model	22D-E4P2H204
Product Family	PowerFlex 40P
Product Type	Variable Frequency Drive (VFD)
Rated Power	2.2 kW / 3 HP
Input Voltage	600V AC
Input Phase	Three-phase
Input Frequency	50/60 Hz
Output Current	4.2 A
Frame Size	B
Enclosure Rating	IP20, open type
Mounting Style	Plate drive
User Interface	Integral LED display; reset-only display configuration
Integrated Filter	No CE-compliant filter
Lifecycle Status	Active

Features & Advantages

Variable speed control: Adjusts AC motor speed to meet application requirements.
Compact design: Frame B construction supports space-efficient panel integration.
Industrial motor control: Suitable for compatible three-phase AC motors.
Local status display: Provides basic drive status and reset functionality.
PowerFlex compatibility: Integrates into suitable industrial drive and automation systems.

Typical Applications

Industrial conveyor systems
Pumps and fans
Material handling equipment
Packaging machinery
General-purpose motor speed control

Important Notes

This model is rated for 600V AC three-phase input. It is not intended for direct connection to a 380–480V supply.
The H204 suffix identifies the plate-drive configuration; it differs from the N104 panel-mount and F104 flange-mount versions.
The drive does not include a CE-compliant filter.
Confirm motor nameplate ratings, installation requirements, and compatibility before ordering.
