A-B 2198-D006-ERS3 Kinetix Servo Drive Module

2198-D006-ERS3
2198-D006-ERS3

A-B 2198-D006-ERS3 Kinetix Servo Drive Module

A-B 2198-D006-ERS3 Kinetix Servo Drive Module

  • Item NO.:

    2198-D006-ERS3

  • Payment:

    T/T

  • Price:

    $1000

  • Product Origin:

    USA

  • Color:

    NEW

  • Product weight:

    0.01KG

  • Lead Time:

    In stock
Inquire Now

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us

                                                                                                                                                                                                                                                                • https://images.openai.com/static-rsc-4/F9q2B-fJYHHEBgG3QgMAkIOd5LpgRo38Kl_vGNDtUMwicN2ZfTMdC9Zc7abehEnEoMDa0T1g6-uFh4xCTcNcuY-muUPl3vAGY3Ru_wxbmxVcXt01wy3z5sblYXcqeQGMJuSLItKU6MwlPDKYw5wU9oa3O8Ka9Iw8DxeUy4AqVnn0H6cP4pQR_MPv9wvLQ0m-?purpose=fullsize

                                                                                                                                                                                                                                                                • A-B 2198-D006-ERS3 Kinetix 5700 Dual-Axis Servo Drive

                                                                                                                                                                                                                                                                  Product Overview

                                                                                                                                                                                                                                                                  The Allen-Bradley 2198-D006-ERS3 is a Kinetix 5700 Dual-Axis Inverter Module with a compact 55 mm width. It provides two servo axes and is designed for high-performance motion control systems using the Kinetix 5700 platform. Rockwell currently lists the product as Active.

                                                                                                                                                                                                                                                                  Key Technical Specifications

                                                                                                                                                                                                                                                                  Parameter Specification
                                                                                                                                                                                                                                                                  Brand Allen-Bradley
                                                                                                                                                                                                                                                                  Model 2198-D006-ERS3
                                                                                                                                                                                                                                                                  Product Type Dual-Axis Servo Drive / Inverter
                                                                                                                                                                                                                                                                  Series Kinetix 5700
                                                                                                                                                                                                                                                                  Axes 2
                                                                                                                                                                                                                                                                  Continuous Output Current 2 × 2.5 A RMS
                                                                                                                                                                                                                                                                  Continuous Output Current 2 × 3.5 A 0-pk
                                                                                                                                                                                                                                                                  Peak Output Current 2 × 8.8 A 0-pk
                                                                                                                                                                                                                                                                  Continuous Power 2 × 0.9 kW @ 240 V; 2 × 1.7 kW @ 480 V
                                                                                                                                                                                                                                                                  DC Bus Voltage Up to 747 V DC
                                                                                                                                                                                                                                                                  Module Width 55 mm
                                                                                                                                                                                                                                                                  Velocity Loop Bandwidth 400 Hz
                                                                                                                                                                                                                                                                  Current Loop Bandwidth 1000 Hz
                                                                                                                                                                                                                                                                  PWM Frequency 4 kHz
                                                                                                                                                                                                                                                                  Communication EtherNet/IP
                                                                                                                                                                                                                                                                  Safety ERS3 Integrated Safe Torque Off
                                                                                                                                                                                                                                                                  Feedback Hiperface DSL / compatible feedback options
                                                                                                                                                                                                                                                                  Mounting Kinetix 5700 shared-bus system
                                                                                                                                                                                                                                                                  Lifecycle Active

                                                                                                                                                                                                                                                                  Rockwell's specifications identify the 2198-D006-ERS3 as a 2 × 2.5 A dual-axis module, with a 55 mm width and up to 2 × 1.7 kW continuous output at 480 V.

                                                                                                                                                                                                                                                                  Advantages & Features

                                                                                                                                                                                                                                                                  • Dual-axis servo control in a compact module
                                                                                                                                                                                                                                                                  • High power density with only 55 mm module width
                                                                                                                                                                                                                                                                  • Integrated EtherNet/IP motion control
                                                                                                                                                                                                                                                                  • ERS3 Safe Torque Off (STO) functionality
                                                                                                                                                                                                                                                                  • 400 Hz velocity-loop and 1000 Hz current-loop bandwidth
                                                                                                                                                                                                                                                                  • Supports multiple Kinetix servo motor and feedback configurations
                                                                                                                                                                                                                                                                  • Zero-stack design helps reduce cabinet space

                                                                                                                                                                                                                                                                  Applications

                                                                                                                                                                                                                                                                  • High-performance servo motion control
                                                                                                                                                                                                                                                                  • Packaging machinery
                                                                                                                                                                                                                                                                  • Robotics and automation
                                                                                                                                                                                                                                                                  • Material handling
                                                                                                                                                                                                                                                                  • Machine tools
                                                                                                                                                                                                                                                                  • Printing and converting equipment
                                                                                                                                                                                                                                                                  • Multi-axis coordinated motion systems
                                                                                                                                                                                                                                                                •

The structure and details of the product：
