A-B 20F11NC015JA0NNNNN PowerFlex 753 Drive

Allen‑Bradley 20F11NC015JA0NNNNN

PowerFlex 753 AC Drive (7.5 kW / 10 HP, 400V)

Specifications

• Input Voltage: 380–480 VAC, 3‑phase, 50/60 Hz
• Output Power:
  • Normal Duty (ND): 7.5 kW (10 HP)
  • Heavy Duty (HD): 5.5 kW (7.5 HP)
• Output Current: 15.4 A (continuous)
• Frame Size: 2 (IP20)
• Enclosure: IP20 / NEMA Type Open, panel mount
• Control: Sensorless vector control, V/Hz
• Embedded I/O: 3×DI, 1×Relay DO, 1×Transistor DO, 1×AI, 1×AO, 1×PTC input
• EMC Filter: Integrated (CE compliant)
• Dynamic Brake: Brake transistor onboard (no internal resistor)
• HMI: No HIM (blank cover)
• Communication: No comm module (slot available)
• Dimensions (W×H×D): ~130 × 300 × 170 mm
• Weight: ~10 kg
• Certifications: UL, cUL, CE, CCC, RoHS, TÜV FS
• Status: Active

Key Features

• Cost‑effective general‑purpose drive: Ideal for conveyors, fans, pumps, and material handlingRockwell Automation
• Embedded I/O: Reduces need for external I/O modules, simplifies system design
• Integrated EMC filter: Meets CE requirements out of the box
• Sensorless vector control: High torque at low speeds, no encoder required
• Brake transistor standard: Supports dynamic braking (external resistor required)
• Compact IP20 frame: Space‑saving panel mountingRockwell Automation
• Safety‑ready: Compatible with Safe Torque Off (STO) options
