A-B 2098-DSD-HV030X-DN Ultra 3000 Servo Drive

Product Description

Allen-Bradley 2098-DSD-HV030X-DN is an Ultra 3000 Digital Servo Drive manufactured by Rockwell Automation. It is a high-voltage servo drive designed for precise motion control applications, providing control of Allen-Bradley servo motors in industrial automation systems.

This model includes DeviceNet communication, indexing capability, and supports high-performance servo positioning applications. It is rated as a 3 kW class servo drive with high-voltage input.

Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 2098-DSD-HV030X-DN
• Product Type: Digital Servo Drive
• Series: Ultra 3000
• Drive Type: High Voltage Servo Drive
• Communication: DeviceNet
• Control Mode: Digital Servo Control
• Rated Power: 3 kW
• Input Voltage: 230…480V AC
• Phase: 3 Phase
• Output Current: Approx. 4 A
• Peak Current: Approx. 14 A
• Feedback Support: Incremental Encoder Feedback
• Mounting: Panel Mount
• Software: UltraWare / Motion configuration tools
• Status: Discontinued product series (Rockwell Automation announced discontinuation of Ultra 3000 products)

Functions

• Controls AC servo motors for precise motion applications
• Provides accurate speed, torque, and position control
• Receives commands through DeviceNet network
• Supports indexing motion profiles
• Provides encoder feedback processing
• Controls machine positioning and coordinated motion systems

Advantages & Features

• High-performance digital servo control
• Integrated DeviceNet communication
• Supports indexing operations without requiring external motion controller
• Precise positioning and speed regulation
• Compatible with Allen-Bradley motion control systems
• Suitable for demanding industrial automation applications

Applications

• CNC machines
• Packaging equipment
• Robotics systems
• Semiconductor equipment
• Material handling systems
• Precision positioning machinery
• Automated production lines

Notes

• 2098-DSD-HV030X-DN is a servo drive, not a standard AC inverter/VFD
• Requires compatible Allen-Bradley servo motor and feedback device
• Verify motor voltage, current, and feedback type before replacement
• DeviceNet network configuration is required for communication
• This model is discontinued; replacement selection should consider system compatibility
