A-B 2090-CFBM7DFCDAF05 Kinetix Servo Motor Feedback Cable

Product Overview

The Allen-Bradley 2090-CFBM7DF-CDAF05 is a Kinetix 2090 continuous-flex motor feedback cable for servo motor/actuator feedback applications. It uses a SpeedTec DIN (M7) motor-end connector and flying leads at the drive end, with a 5 m length. The CD configuration supports high-resolution or incremental encoder applications.

Key Technical Specifications

Rockwell's cable documentation identifies the 2090-CFBM7DF-CDAFxx family as continuous-flex feedback cables with SpeedTec DIN motor connections and flying leads at the drive end; the 05 suffix denotes 5 m.

Advantages & Features

• 5 m standard cable length
• Continuous-flex construction for demanding motion applications
• SpeedTec DIN connector for secure motor connection
• Flying-lead drive-end configuration for flexible wiring
• Supports high-resolution and incremental feedback
• Designed for repeated movement in servo applications
• Helps simplify Kinetix motion-system installation

Applications

• Servo motor feedback
• Kinetix multi-axis motion systems
• Packaging machinery
• Machine tools
• Robotics and automation
• Material handling
• High-speed positioning systems
