A-B 2090-CFBM7DF-CEAA40 Feedback Cable

Allen‑Bradley 2090‑CFBM7DF‑CEAA40

Kinetix MP‑Series Servo Feedback Cable (40 m, Standard Non‑Flex)

Specifications

• Length: 40 meters
• Cable Type: Standard (Non‑Flex), for stationary installation
• Application: Motor feedback only (SIN/COS high‑resolution encoder or resolver)
• Connectors:
  • Motor end: SpeedTec DIN threaded connector
  • Drive end: Flying leads (open wires)
• Voltage Rating: 600 V
• Jacket Material: Thermoplastic (green)
• Shielding: Overall shielded for noise immunity
• Bend Radius: ~69 mm (2.7 in)
• Certifications: UL, CE, CSA
• Status: Active

Features

• High‑resolution feedback: Optimized for SIN/COS encoders and resolvers, ensuring precise motion control
• Durable construction: Industrial‑grade thermoplastic jacket, resistant to oil, coolant, and hydrolysis
• Easy installation: SpeedTec DIN connector provides secure, quick motor connection; drive‑end flying leads simplify wiring to drives
• Noise suppression: Overall shield reduces electromagnetic interference (EMI) in industrial environments
• Cost‑effective: Standard non‑flex design for fixed installations, offering reliable performance at lower cost than continuous‑flex cables
