- - Allen‑Bradley 1794-AENT FLEX I/O Ethernet Adapter Module

    Product Overview

    This Ethernet/IP communication adapter serves as the network gateway for FLEX 1794 distributed remote I/O systems. It connects FLEX I/O racks to the Ethernet/IP industrial network, enabling data exchange between the ControlLogix PLC controller and field digital/analog I/O modules.

    Core Specifications

    Communication protocol: Ethernet/IP, supports implicit and explicit messaging

    Port: Single 10/100 Mbps auto-sensing RJ45 Ethernet port

    Max I/O capacity: Supports up to 8 FLEX I/O modules on one local rack

    Backplane power draw: 240 mA @ 24 VDC

    Operating temperature range: 0°C ~ 60°C, storage -40°C ~ 85°C

    Mounting: DIN rail installation, IP20 cabinet use only

    Diagnostic LEDs: Module status, network link, activity and fault indicators

    Certifications: UL, cUL, CE, Class I Div 2 hazardous location certified

    Supports RIUP hot-swap replacement of I/O modules without powering down the rack

    Main Functions

    Transmit real-time digital input/output and analog signal data between field FLEX I/O and upper PLC via Ethernet/IP

    Distribute 24VDC backplane power to all installed FLEX I/O modules in the rack

    Detect module faults, short circuits and network disconnections, upload alarm information to the controller

    Realize remote distributed signal collection for scattered field equipment to reduce long-distance wiring costs

    Key Advantages

    Compact size saves cabinet installation space; high-speed Ethernet communication ensures fast I/O data refresh. Compatible with all standard 1794 series digital and analog I/O modules. Certified for hazardous industrial environments, stable operation under complex electromagnetic interference. Hot-swap design minimizes production downtime during maintenance.

    Typical Applications

    Water treatment distributed signal stations, packaging production line remote I/O, metallurgy auxiliary equipment control, logistics conveying systems, chemical plant Class I Div 2 remote monitoring cabinets
