Allen‑Bradley 1783-MMX14T2S Stratix 5800 Gigabit Ethernet Expansion Module

Product Overview

Model Code Breakdown

• 1783: Stratix industrial Ethernet switch product family
• MMX: Modular expansion add-on card for Stratix 5800 chassis
• 14T: 14× 10/100/1000BASE-T copper RJ45 ports
• 2S: 2× Gigabit SFP slots for fiber uplink media

Core Technical Specifications

Port Configuration

• 14 × Auto-sensing 10/100/1000 Mbps RJ45 copper ports (auto MDI-X, screw terminal cabling)
• 2 × Gigabit SFP transceiver slots: Support multi-mode / single-mode fiber SFP modules for long-distance backbone links
• All ports full/half duplex auto-negotiation, IEEE 802.3 compliant

Industrial Network & Automation Protocols

• Native EtherNet/IP, CIP Sync, IEEE 1588 PTP Precision Time Protocol for synchronized multi-axis motion control
• DLR (Device Level Ring) topology support with <3ms failover recovery for uninterrupted production networks
• Layer 2 switching standard; compatible with Layer 3 routing-capable Stratix 5800 base chassis
• Supports QoS traffic prioritization to isolate real-time motion I/O traffic from office IT data

Electrical Power

• Powered via Stratix 5800 main backplane, no separate external DC power supply required
• Operating input voltage range: 18–32 VDC (nominal 24 VDC industrial bus)
• Max power consumption: ~12 W
• Built-in fault alarm relay contact for remote system monitoring

Mechanical & Environmental

• Mounting: Plug-in hot-swap module for Stratix 5800 modular DIN rail chassis
• Dimensions (H×W×D): 152 × 64 × 122 mm
• Net weight: ~0.9 kg
• Enclosure rating: IP20 indoor cabinet use only
• Operating temperature: -25 °C ~ +60 °C (wide cold/high temp industrial tolerance)
• Storage temperature: -40 °C ~ +85 °C
• Humidity: 5%–95% non-condensing
• Vibration & Shock: Compliant with IEC 60068 industrial environmental standards

Diagnostics & Indicators

• Per-port bi-color LED status (Link/Activity, Speed)
• Module health, SFP slot, fault alarm LEDs on front panel
• SD card slot on main Stratix base for switch configuration backup/logging

Certifications

Main Functions

1. High-Density Network Port Expansion



   Adds 14 gigabit copper ports to Stratix 5800 switch chassis, connecting large numbers of PLCs, HMIs, servo drives, remote I/O blocks, sensors and industrial cameras without deploying extra standalone switches, saving cabinet space and wiring cost.
2. Fiber Backbone Redundant Uplink



   Two SFP slots support fiber transceivers to create long-distance, noise-immune plant backbone connections. Fiber links eliminate electromagnetic interference from high-power inverters and servo motors, and enable redundant ring/star network topologies for system fault tolerance.
3. Real-Time Motion & Time Synchronization



   CIP Sync and IEEE 1588 PTP deliver microsecond-level time alignment across all network nodes, critical for multi-axis coordinated motion (electronic cam, flying shear, gantry synchronization) on packaging, automotive and CNC machinery.
4. Hot-Swap Maintenance Without Line Shutdown



   Modular plug-in design allows replacement of faulty expansion modules while the main switch chassis and production network remain online, drastically cutting unplanned equipment downtime during troubleshooting and upgrades.
5. Industrial Network Fault Diagnostics & Alarm Output



   Built-in alarm relay triggers external light/horn alarms for port failure, link loss or module hardware faults. All port, traffic and error logs are stored for remote troubleshooting via Studio 5000 or network management software.
6. IT/OT Network Segmentation & Traffic QoS



   Configurable VLANs separate production control (OT) traffic from office IT networks; QoS prioritization ensures EtherNet/IP motion and safety data transmit first, avoiding communication lag or machine safety trips caused by background data congestion.

Key Advantages

• Gigabit full-speed ports eliminate bandwidth bottlenecks for high-speed multi-servo motion control systems
• Wide -25°C cold-start rating fits cold storage, outdoor cabinet and northern workshop environments
• DLR ring redundancy ensures <3ms network recovery after single cable break, preventing full production halt
• Unified Rockwell automation ecosystem, fully compatible with all Logix controllers and Kinetix motion drives
• Hot-swap capability removes the need for full network power-off during module replacement
• Dual SFP fiber slots provide flexible long-distance plant backbone layout and redundant uplink paths
• Hazardous location certification for chemical, oil & gas, water treatment and mining process facilities
• Centralized switch configuration backup via SD card for fast system restoration after hardware replacement
