A-B 1783-CMS10DP Managed Ethernet Switch

Product Description

Allen-Bradley 1783-CMS10DP is a Stratix 5200 Managed Ethernet Switch manufactured by Rockwell Automation. It is designed for industrial Ethernet networks, providing reliable communication, network management, and redundancy features for automation systems.

The switch provides 8 copper Gigabit Ethernet ports and 2 combo copper/fiber Gigabit ports, with full firmware functionality and support for Device Level Ring (DLR) network redundancy.

Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 1783-CMS10DP
• Product Type: Managed Industrial Ethernet Switch
• Series: Stratix 5200
• Total Ports: 10 ports
• Copper Ports: 8 × 10/100/1000 Mbps RJ45
• Combo Ports: 2 × 10/100/1000 Mbps Copper/Fiber ports
• Network Type: Industrial Ethernet / EtherNet/IP
• Firmware: Full Firmware
• Redundancy: Device Level Ring (DLR) Support
• Mounting: DIN Rail Mount
• Protection Rating: IP30
• Operating Temperature: -40…60 °C (-40…140 °F)
• Power Supply: 12…48 VDC

Functions

• Provides managed Ethernet communication between industrial devices
• Connects PLCs, HMIs, drives, remote I/O, and automation equipment
• Supports network monitoring and configuration
• Provides EtherNet/IP network management
• Supports DLR ring topology for improved network availability
• Provides diagnostics for industrial network troubleshooting

Advantages & Features

• Industrial-grade managed switch design
• Supports Gigabit Ethernet communication
• Flexible copper and fiber connectivity
• Built-in DLR redundancy capability
• DIN rail mounting for control cabinets
• Wide operating temperature range
• Compatible with Rockwell Automation control systems
• Supports advanced network management functions

Applications

• Factory automation networks
• PLC communication systems
• Motor control centers (MCC)
• Remote I/O networks
• Machine automation equipment
• Process control systems
• Industrial Ethernet infrastructure

Notes

• 1783-CMS10DP is a managed Ethernet switch, not a PLC module
• Requires proper network configuration before commissioning
• Confirm IP address settings and EtherNet/IP parameters
• Use industrial-grade Ethernet cables for reliable communication
• Verify power supply voltage (12–48VDC) before installation
