A-B 1769-IQ32 Digital Input Module

Allen‑Bradley 1769‑IQ32 – CompactLogix 32‑Point 24V DC Digital Input Module

Specifications

• Series: 1769 Compact I/O (for CompactLogix/MicroLogix 1500)
• Channels: 32 digital inputs (4 groups × 8 points)
• Input Voltage: 10–30V DC (24V DC nominal)Rockwell Automation
• Logic Type: Sink/source selectable
• On‑state Voltage: ≥10V DC; Off‑state: ≤5V DC
• Input Delay: 8 ms (on)
• Isolation: 1200V AC for 1 s (input‑to‑bus, group‑to‑group)
• Current: On‑state min 2 mA; Inrush max 250 mA
• Power Dissipation: 4.6 W; 170 mA @ 24V DC
• Operating Temp: 0 °C to +60 °C (32 °F to +140 °F)
• Dimensions (H×W×D): 118 × 52.5 × 87 mm (4.65 × 2.07 × 3.43 in)
• Weight: ~0.44 kg (0.97 lb)
• Lifecycle: Active (mature)Rockwell Automation

Features

• High‑density 32‑point input: Saves cabinet space
• Sink/source configurable: Flexible wiring for NPN/PNP sensors
• High isolation rating: Protects controller from field noise
• Compact design: DIN rail or panel mount
• Diagnostic LEDs: Per‑channel status indication
• Seamless integration: Works with CompactLogix/MicroLogix 1500
