Allen-Bradley 1768-PB3 CompactLogix Power Supply Module

Product Overview

Allen-Bradley 1768-PB3 CompactLogix L4x DC Power Supply Module is a 24V DC power supply module designed for CompactLogix 1768-L4x controller systems. It provides stable DC power for the CompactLogix controller platform and connected modules, ensuring reliable operation of industrial automation systems.

Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 1768-PB3
• Product Type: CompactLogix DC Power Supply Module
• Series: CompactLogix 1768
• Input Voltage: 24V DC (16.8…31.2V DC)
• Input Power: 112 W max
• Efficiency: Approx. 80% at 24V DC
• Power Dissipation: 22 W max
• Mounting: CompactLogix System Mounting
• Enclosure Type: Open Style
• Isolation Voltage: 250V reinforced insulation
• Operating Temperature: Industrial Environment
• Weight: Approx. 1.01 kg

Advantages & Features

• Provides stable 24V DC power for CompactLogix systems
• Designed specifically for 1768 CompactLogix L4x controllers
• High reliability for continuous industrial operation
• Compact design saves control cabinet space
• Easy integration with CompactLogix automation platforms
• Built for industrial environments with high durability
• Helps maintain stable PLC system performance

Applications

• Factory automation systems
• PLC control cabinets
• Machine automation equipment
• Manufacturing production lines
• Process control systems
• Industrial monitoring systems
• OEM automation equipment

Precautions

• Confirm compatibility with CompactLogix 1768 system before installation
• Verify input voltage requirements before powering on
• Use proper grounding and wiring methods
• Disconnect power before installation or maintenance
• Do not exceed rated power specifications
• Ensure sufficient ventilation inside the control cabinet
