Allen-Bradley 1763-NC01 MicroLogix Communication Cable

Product Overview

Allen-Bradley 1763-NC01 MicroLogix Communication Cable is a dedicated communication cable designed for MicroLogix 1100 controllers. It connects the controller Channel 0 (8-pin DIN port) to an RS-485 (6-pin Phoenix terminal) interface, allowing serial communication with external devices and networks.

Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 1763-NC01
• Product Type: PLC Communication Cable
• Series: MicroLogix 1100
• Communication Interface: RS-485
• Connector 1: 8-pin Mini DIN
• Connector 2: 6-pin Phoenix Terminal Block
• Cable Length: Approx. 30 cm
• Communication Modes:
  • DH-485
  • Modbus RTU
  • DF1 Half-Duplex
• Application: MicroLogix 1100 Channel 0 Communication Port

Advantages & Features

• Provides stable serial communication between PLC and external devices
• Designed specifically for MicroLogix 1100 controllers
• Supports multiple industrial communication protocols
• Compact design for easy installation
• Simplifies RS-485 network connection
• Reliable connection for programming and data exchange
• Suitable for industrial automation environments

Applications

• PLC programming and configuration
• Industrial communication networks
• RS-485 device connections
• Machine automation systems
• Factory control systems
• Process monitoring equipment
• Modbus RTU communication applications

Precautions

• Confirm compatibility with MicroLogix 1100 controllers before use
• Ensure correct RS-485 wiring polarity
• Avoid connecting to incompatible communication ports
• Check communication parameters such as baud rate and parity
• Disconnect power before installation or removal
• Avoid excessive bending or mechanical damage to the cable
