Allen-Bradley 1763-L16BBB MicroLogix 1100 Controller

Product Description

Allen-Bradley 1763-L16BBB is a MicroLogix 1100 Series Programmable Logic Controller (PLC) designed for small-scale industrial automation applications. It integrates digital I/O, analog inputs, Ethernet communication, RS-232/RS-485 serial communication, and an embedded LCD display, providing flexible control solutions for machine automation and process applications.

Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 1763-L16BBB
• Series: MicroLogix 1100
• Product Type: Programmable Logic Controller (PLC)
• Power Supply: 24V DC
• Digital Inputs: 10 × 24V DC Inputs
• Analog Inputs: 2 × 0–10V DC Voltage Inputs
• Digital Outputs:
  • 2 × Relay Outputs
  • 4 × 24V DC FET Outputs
• Total I/O Points: 16 Points
• Memory: 8 KB User Memory
• Communication:
  • Ethernet/IP Messaging
  • DF1
  • DH-485
  • Modbus RTU
  • ASCII
• Display: Integrated LCD Display
• Expansion: Supports MicroLogix 1762 Expansion I/O Modules
• Mounting: DIN Rail / Panel Mount
• Operating Temperature: -20°C to +65°C

Advantages & Features

• Compact PLC design saves installation space
• Built-in Ethernet communication simplifies system integration
• Integrated LCD display allows status monitoring and parameter adjustment
• Supports analog signal processing for flexible control applications
• Fast DC inputs and FET outputs support high-speed control tasks
• Expandable I/O capability for future system upgrades
• Reliable Allen-Bradley industrial design for continuous operation

Applications

• Factory automation systems
• Packaging machinery
• Conveyor control systems
• Pump and motor control
• Material handling equipment
• Small production lines
• Machine monitoring systems
• Building automation applications

Notes

• Verify PLC program compatibility before replacement
• Confirm 24V DC power supply requirements before installation
• Check I/O wiring configuration carefully
• Backup existing programs before maintenance
• Ensure communication settings match the connected devices
• Product has been discontinued by Rockwell Automation; evaluate replacement options for new designs
