A-B 1761-L20AWA-5A MicroLogix 1000 Programmable Controller

Product Overview

Brand: Allen-Bradley (A-B)
Model: 1761-L20AWA-5A
Product Type: MicroLogix 1000 Programmable Controller
I/O Type: Digital + Analog
Power Supply: 120/240 VAC
Communication: RS-232 / DF1
Memory: 1 KB EEPROM
Status: Discontinued by Rockwell Automation on May 18, 2017.

Key Technical Specifications

Rockwell's documentation confirms the 1761-L20AWA-5A configuration as 12 AC inputs, 4 analog inputs, 8 relay outputs and 1 analog output.

Advantages & Features

• Integrated PLC controller with both digital and analog I/O.
• 12 AC digital inputs for direct monitoring of 120 VAC field signals.
• Built-in analog I/O supports voltage and current signals.
• 8 relay outputs provide flexible control of external devices.
• Compact MicroLogix design saves control-panel space.
• RS-232 / DF1 communication supports programming and system communication.
• 1 KB EEPROM provides nonvolatile program storage.
• Suitable for standalone machine-control applications.

Typical Applications

• Industrial machine control
• Packaging machinery
• Conveyor systems
• Material handling
• Pump and motor control
• Production and assembly equipment
• HVAC and building automation
• Small process-control systems
• Factory automation
