Specifications

• Channels: 8 configurable universal inputs
• Input Types & Ranges:
  • Voltage: ±50 mV, ±100 mV, 0–5 V, 1–5 V, 0–10 V, ±10 V
  • Current: 0–20 mA, 4–20 mA
  • Thermocouple (TC): J, K, T, E, R, S, N, B, C
  • RTD/Resistance: PT385/3916, Ni618/672, NiFe518, Cu426; 0–150 Ω to 0–4000 Ω
• Resolution: 16–21 bit (filter‑dependent)
• Accuracy: ±0.1% full scale (typical)
• Input Impedance: >1 MΩ (voltage); <250 Ω (current)
• Filter Options: 5 selectable digital filters (per channel)
• Update Rate: 10 Hz to 1000 Hz selectable
• Isolation:
  • Channel‑to‑channel: 12.5 VDC
  • Field‑to‑backplane: 1000 VAC reinforced
• Protection: Overvoltage (14.5 VDC max); Overcurrent (28 mA continuous)
• Backplane Power: 230 mA @ 5 VDC (max)
• Power Consumption: ~3 W
• Operating Temperature: 0 °C to 60 °C
• Mounting: ControlLogix chassis (1 slot)
• Features: Auto‑calibration, built‑in diagnostics, HART capability (optional)

Key Features

1. Universal Input: One module handles voltage, current, thermocouple, and RTD signals.
2. High Resolution & Accuracy: Up to 21‑bit resolution for precise process monitoring.
3. Flexible Filtering: Five user‑selectable filters per channel for noise reduction.
4. Strong Isolation: 1000 VAC field‑to‑backplane isolation for safety and noise immunity.
5. Advanced Diagnostics: Built‑in fault detection and auto‑calibration simplify maintenance.

Applications

• Process monitoring: Temperature, pressure, flow, level, and humidity
• Data acquisition for industrial IoT and condition monitoring
• Food & beverage, pharmaceutical, chemical, water treatment
• General factory automation requiring multi‑sensor input
