A-B 1756-PAR2 ControlLogix Redundant Power Supply Module

Product Overview
The Allen-Bradley 1756-PAR2 is a ControlLogix 85–265 VAC redundant power supply assembly designed to provide increased power-system availability for critical ControlLogix applications. It is a complete bundled kit rather than a single power-supply module.

Technical Specifications

• Model: 1756-PAR2
• Series: ControlLogix
• Type: Redundant AC Power Supply Assembly
• Input Voltage: 85–265 VAC
• Input Frequency: 47–63 Hz
• Output Power: 75 W per power supply
• Output: 5.1 VDC @ 13 A; 3.3 VDC @ 4 A; 1.2 VDC @ 1.5 A; 24 VDC @ 2.8 A
• Operating Temperature: 0–60°C
• Redundant Configuration: Yes
• Mounting: Panel/chassis-mounted components
• Included: 2 × 1756-PA75R, 2 × 1756-CPR2 cables, 1 × 1756-PSCA2 chassis adapter

Advantages & Features

• Provides redundant power for improved system availability
• Helps reduce downtime caused by a single power-supply failure
• Complete factory-configured redundant power supply kit
• Status monitoring and annunciator capability
• Designed specifically for ControlLogix chassis applications

Applications

• Industrial automation
• Process control systems
• Manufacturing equipment
• Critical ControlLogix installations
• Power and energy systems
• Oil & gas and other high-availability applications
