A-B 1756-OW161 ControlLogix Relay Output Module
Item NO.:
1756-OW161Payment:
T/TPrice:
$1000Product Origin:
USAColor:
NEWProduct weight:
0.01KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
The Allen-Bradley 1756-OW16I is a 16-point individually isolated normally-open relay output module for ControlLogix systems. It supports both AC and DC loads and uses a 36-pin removable terminal block.
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley / Rockwell Automation |
| Model | 1756-OW16I |
| Product Type | ControlLogix Relay Output Module |
| Outputs | 16 Normally Open (N.O.) |
| Isolation | Individually isolated |
| DC Operating Voltage | 5–125 V DC |
| AC Operating Voltage | 10–240 V AC |
| Output Rating | 1 A @ 5–30 V DC |
| 0.5 A @ 48 V DC | |
| 0.22 A @ 125 V DC | |
| 1.5 A @ 120 V AC | |
| 0.75 A @ 240 V AC | |
| Output Type | Relay |
| Output Delay | 10 ms max. |
| Backplane Current | 150 mA @ 5.1 V / 24 V |
| Power Dissipation | 4.5 W max. @ 60°C |
| Isolation Voltage | 250 V continuous |
| Terminal Block | 1756-TBCH / 1756-TBS6H |
| Slot Width | 1 slot |
| Status | Active |
Rockwell specifies 16 individually isolated N.O. relay outputs, 5–125 V DC / 10–240 V AC operation, and the load-dependent output ratings above.
