Product Overview

Brand: Allen-Bradley (A-B)
Model: 1756-M08SE
Product Type: ControlLogix 8-Axis SERCOS Servo Module
Communication: SERCOS
Maximum Axes: 8
Installation: ControlLogix chassis
Lifecycle: Active Mature

Key Technical Specifications

Parameter	Specification
Module Type	SERCOS Servo / Motion Module
Number of Axes	Up to 8
Communication	SERCOS
Communication Medium	Fiber-optic
SERCOS Data Rate	4 Mbps
Module Location	1756 ControlLogix Chassis
Backplane Current	5.1 VDC @ 760 mA; 24 VDC @ 2.5 mA
Power Dissipation	5 W maximum
Fiber-Optic Transmission	Up to 32 m plastic fiber / 200 m glass fiber
Programming Software	RSLogix 5000 / Studio 5000
Electronic Keying	Supported
Status Indicators	CP / OK
Product Series	Series B
UPC	612598295999

Rockwell specifies the 1756-M08SE as an 8-axis SERCOS motion module. The SERCOS interface uses fiber-optic communication for high-speed, noise-resistant communication between the ControlLogix platform and servo drives.

Advantages & Features

8-axis motion control for coordinated servo applications.
High-speed 4 Mbps SERCOS communication.
Fiber-optic communication provides excellent noise immunity.
Supports real-time communication with compatible servo drives.
Supports high-resolution motor position feedback.
Supports single-turn and multi-turn absolute feedback.
Configuration and drive setup can be performed through RSLogix 5000 / Studio 5000.
Long fiber-optic cable distances simplify distributed motion-system layouts.

Typical Applications

Servo motion-control systems
Packaging machinery
Robotics and automated machinery
CNC and machine tools
Printing and converting equipment
Material handling
High-speed production lines
Multi-axis positioning systems

Important Precautions

Verify that the ControlLogix chassis and controller support the required motion-control configuration.
Confirm compatibility between the 1756-M08SE and the connected SERCOS servo drives.
Use the correct fiber-optic cable and observe the specified transmission distance.
Keep fiber-optic connectors clean and protected from damage.
Configure the SERCOS ring parameters correctly in Studio 5000/RSLogix 5000.
Disconnect power before installing or removing the module.
Check the Series and firmware revision when replacing an existing module, as compatibility can depend on the system configuration. Rockwell currently lists the 1756-M08SE as Active Mature.
