A-B 1756-IT612 ControlLogix Thermocouple Input Module
Item NO.:
1756-IT612Payment:
T/TPrice:
$1000Product Origin:
USAColor:
NEWProduct weight:
0.01KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
The Allen-Bradley 1756-IT6I2 is a 6-channel individually isolated thermocouple/mV input module for ControlLogix systems. It supports multiple thermocouple types and includes two cold junction compensation (CJC) sensors. Note that Rockwell lists this model as discontinued since March 31, 2017.
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley / Rockwell Automation |
| Model | 1756-IT6I2 |
| Product Type | Enhanced Isolated Thermocouple/mV Input Module |
| Channels | 6 individually isolated inputs |
| CJC | 2 Cold Junction Compensation sensors |
| Input Range | -12 to 78 mV / -12 to 30 mV |
| Resolution | 16-bit |
| Thermocouple Types | B, C, D, E, J, K, L, N, R, S, T |
| Linearization | ITS-90 |
| Isolation Voltage | 250 V continuous |
| Overvoltage Protection | 120 V AC/DC |
| Current Draw @ 5.1 V | 200 mA |
| Current Draw @ 24 V | 150 mA |
| Power Dissipation | 4.6 W max. |
| Channel Bandwidth | 15 Hz |
| Connection | 1756-TBNH / 1756-TBSH |
| Slot Width | 1 slot |
| Conversion | Sigma-Delta |
| Status | Discontinued |
| Discontinued Date | March 31, 2017 |
| Country of Origin | United States |
Specifications are based on Rockwell Automation's product page and ControlLogix technical documentation.
