A-B 1756-CMS1B4 ControlLogix Communication Module

Allen-Bradley 1756-CMS1B4 ControlLogix Communication Module

Product Description

The Allen-Bradley 1756-CMS1B4 is a ControlLogix Compute Module designed for integration into the ControlLogix 1756 chassis system. Unlike traditional communication modules, it provides an embedded computing environment that can run custom applications and exchange data directly with ControlLogix controllers through the chassis backplane.

The module is suitable for edge computing, data processing, custom software applications, and industrial automation systems requiring additional computing capability.

Technical Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 1756-CMS1B4
• Product Type: ControlLogix Compute Module
• Series: ControlLogix 1756
• Function: Embedded computer / industrial computing module
• Operating System: Windows 10 IoT Enterprise 64-bit
• Processor: Intel Atom processor
• Memory: 4 GB RAM
• Storage: Industrial flash storage
• Backplane Communication: ControlLogix chassis backplane
• Ethernet Ports: 2 × Gigabit Ethernet
• USB Interface: USB 3.0
• Display Interface: DisplayPort
• Mounting: ControlLogix chassis slot mounting
• Power Supply: Supplied through 1756 chassis backplane
• Operating Temperature: Industrial rated environment

Advantages & Features

• Adds PC-level computing capability to ControlLogix systems
• Runs custom applications alongside PLC control
• Direct communication with ControlLogix controller via backplane
• Dual Gigabit Ethernet ports for network integration
• Supports industrial data processing and edge computing applications
• Integrated DisplayPort for local visualization
• Compact modular design compatible with ControlLogix chassis

Applications

• Industrial edge computing
• Machine data collection
• Industrial IoT applications
• SCADA and HMI integration
• Custom automation software
• Manufacturing data analysis
• Advanced ControlLogix systems

Notes / Precautions

• Requires a compatible ControlLogix 1756 chassis
• Verify firmware and software compatibility before installation
• Confirm application requirements for Windows IoT environment
• Ensure proper Ethernet network configuration
• Installation and configuration should be performed by qualified personnel
