The A-B 1738-VHSC24M23 is an Allen-Bradley ArmorPOINT I/O Very High-Speed Counter Module, designed for high-frequency pulse and encoder counting. It is a 1-channel, 24 VDC counter module with M23 connectors. Rockwell lists it as discontinued effective December 31, 2025, with no planned Rockwell replacement.

Key Technical Specifications

The module can process encoder, pulse-generator and mechanical-switch signals, with counting rates up to 1 MHz depending on the selected configuration. It can also use count/rate information to activate its two embedded outputs very quickly.

Advantages & Features

• 1 MHz high-speed counting capability
• Supports counter and encoder X1/X2/X4 configurations
• Programmable input filtering
• Supports pulse-width-modulated signals
• Two embedded outputs for fast control actions
• M23 industrial connectors for on-machine installation
• Designed for distributed ArmorPOINT I/O systems
• Suitable for high-frequency pulse and speed measurement applications

Typical Applications

• Rotary encoder feedback
• High-speed counting
• Conveyor speed measurement
• Pulse/frequency measurement
• Position and motion monitoring
• Packaging machinery
• Material handling equipment
• Factory automation
