Allen-Bradley 1503VC-BMC5 IntelliVAC Control Module

Product Overview

The Allen-Bradley 1503VC-BMC5 IntelliVAC Control Module is a medium voltage contactor control module designed for Bulletin 1502 vacuum contactors used in medium voltage motor control systems. It provides intelligent control, monitoring, and protection functions for electrically held or mechanically latched vacuum contactors. The module supports 120/240 VAC or 125/250 VDC control power and is suitable for 400A and 800A vacuum contactor applications.

Specifications

Advantages & Features

• Intelligent control for medium voltage vacuum contactors
• Supports electrically held and mechanical latch contactors
• Provides reliable contactor operation and status monitoring
• Reduces wiring complexity compared with traditional control systems
• Compact modular design for medium voltage controllers
• High reliability for continuous industrial operation
• Compatible with Allen-Bradley medium voltage motor control systems
• Improves system safety and operational efficiency

Applications

• Medium Voltage Motor Control Systems
• Industrial Power Distribution
• Mining Equipment
• Oil & Gas Facilities
• Power Generation Systems
• Water Treatment Plants
• Heavy Industrial Machinery
• Factory Automation Systems

Precautions

• Verify compatibility with the correct vacuum contactor model before installation.
• Confirm control voltage requirements.
• Ensure proper wiring of control and status terminals.
• Follow medium voltage safety procedures.
• Avoid installation in environments exceeding specified conditions.
• Disconnect power before maintenance.
