Allen‑Bradley 1492-AIFM8-3 – 8-Channel Analog Interface Module

Specifications

• Channel Quantity: 8 analog signal channels
• Connector: 20-pin ribbon cable connector for Rockwell analog I/O modules
• Signal Compatibility: 4–20mA current loop, 0–10V DC voltage analog signals
• Terminals: Dual screw terminals for each channel, convenient for transmitter power daisy chain
• Wire Range: 14–22 AWG solid/stranded copper wire
• Power Bus: Split isolated power rail, two groups of 4 channels to reduce ground loop noise
• Circuit Rating: Max 2 A per channel
• Mounting: Standard 35 mm DIN rail
• Operating Temperature: 0 °C ~ +60 °C
• Humidity: 5%–95% RH, non-condensing
• Weight: Approx. 0.18 kg
• Certifications: UL/cULus, CE, CSA

Key Features

• Compact 8-channel layout for small analog I/O stations, saves cabinet installation space
• Dual screw terminals simplify field wiring for temperature, pressure, flow transmitters
• Isolated segmented power bus suppresses ground loop interference common in analog measurement circuits
• Keyed 20-pin ribbon cable connector avoids reverse plugging and wiring errors
• Matches all standard Rockwell analog modules (1756 ControlLogix / 1794 FLEX I/O analog cards)
• No built-in fuses, clean layout for low-risk analog signal loops without frequent short-circuit issues
• Uniform wiring standard simplifies on-site commissioning, maintenance and fault troubleshooting

Applications

• Termination of 4–20mA process transmitters (temperature, flow, level, pressure sensors)
• Small-scale process control cabinets, water treatment, food & beverage machinery
• Analog signal collection for valve position feedback, variable frequency drive analog signals
• Distributed remote FLEX I/O stations with limited analog input/output points
