- - Allen‑Bradley 1489-A1C050 Miniature Circuit Breaker

    Product Overview

    Single-pole miniature circuit breaker from Bulletin 1489-A series, C trip curve with 5A rated current. Used for overload and short-circuit protection of low-power branch circuits inside industrial control cabinets, protecting PLC power supplies, sensors, relays, solenoid valves and other control loads.

    Core Specifications

    Poles: 1-pole

    Rated current: 5 A

    Trip characteristic: C curve (for inductive loads with high startup inrush current)

    Rated voltage: 240 VAC / 48 VDC

    Short-circuit breaking capacity: 10 kA at 240 VAC

    Terminals: Screw terminals, compatible with 24–12 AWG wires

    Mounting: Standard 35 mm DIN rail

    Operating temperature: -20 ℃ ~ +60 ℃

    Protection mechanism: Thermal overload trip + electromagnetic instantaneous short-circuit trip

    Status indicator: Mechanical flag showing ON / OFF / tripped status

    Certifications: UL, cUL, CE certified; IP20 indoor cabinet use only

    Main Functions

    Thermal overload protection: Automatically disconnect power under sustained overcurrent to prevent cable overheating and insulation damage

    Instant short-circuit protection: Fast trip upon short-circuit faults to avoid equipment burnout and fire risks

    Manual isolation function: Can be used as a disconnect switch to cut power safely during maintenance

    Safeguard sensitive low-power control components such as power supplies, transmitters and small auxiliary circuits

    Key Advantages

    Ultra-narrow compact housing saves cabinet space. C curve design avoids false tripping caused by coil and power supply startup surge currents. Visible trip indicator speeds up on-site fault troubleshooting. Plug-in DIN rail structure allows quick replacement without complex wiring. Dual thermal-magnetic protection improves overall circuit safety.

    Typical Applications

    PLC auxiliary power branch protection, sensor & transmitter power supply circuits, relay interlock loop protection, small fans, indicator lamps and solenoid valve load protection, secondary distribution circuits inside automation control cabinets
