Allen-Bradley 1444-TBA-RPC-SCW-01 Vibration Monitoring Terminal Base Accessory

Product Description

Allen-Bradley 1444-TBA-RPC-SCW-01 is a Dynamix™ 1444 Series screw clamp removable connector set used with the 1444-TB-A Dynamic Measurement Module Terminal Base. It provides field wiring connection between vibration monitoring modules and external sensors, supporting machine condition monitoring applications.

Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 1444-TBA-RPC-SCW-01
• Series: Dynamix 1444
• Product Type: Removable Screw Clamp Connector Set / Terminal Accessory
• Compatible Terminal Base: 1444-TB-A
• Connector Type: Screw Clamp Removable Plug
• Number of Connectors: 6
• Rated Current: 8 A
• Rated Voltage: 160 V
• Wire Size: 16 AWG (approx. 1.5 mm²)
• Pitch: 3.81 mm
• Connection Type: Screw Terminal
• Mounting: Plug-in Type
• Temperature Rating: Up to 115°C
• Color: Grey

Advantages & Features

• Provides secure connection for vibration monitoring systems
• Screw clamp design ensures reliable field wiring
• Removable connector structure simplifies installation and maintenance
• Reduces wiring replacement time during module servicing
• Designed specifically for Allen-Bradley Dynamix 1444 systems
• Supports predictive maintenance and machine protection applications

Applications

• Vibration monitoring systems
• Rotating machinery condition monitoring
• Motor and pump protection
• Gearbox monitoring
• Turbine and compressor monitoring
• Industrial predictive maintenance systems
• Factory automation equipment

Notes

• Must be used with compatible 1444-TB-A Terminal Base
• Confirm connector configuration before installation
• Ensure correct sensor wiring and polarity
• Disconnect power before replacing connectors
• Avoid damage from static electricity during handling
