Allen-Bradley 1444-TB-A XM Series Terminal Base

Product Description

Allen-Bradley 1444-TB-A is an XM Series Dynamic Measurement Module Terminal Base designed for use with Rockwell Automation XM monitoring modules. It provides electrical connection, module mounting, and signal interface functions between XM condition monitoring modules and field devices.

Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 1444-TB-A
• Series: XM Series
• Product Type: Terminal Base / Module Mounting Base
• Compatible System: XM Dynamic Measurement Modules
• Number of Slots: 1
• Input Voltage: 18…32 VDC
• Maximum Input Current: 8 A
• Mounting: 35 mm DIN Rail / Panel Mount
• Communication Interface: Dynamix Local Bus
• Operating Temperature: -25°C to +70°C
• Humidity: 5…95% RH (non-condensing)
• Protection Type: Open-style enclosure
• Weight: Approx. 204 g

Advantages & Features

• Provides reliable connection between XM modules and field wiring
• Simplifies installation and replacement of monitoring modules
• Supports DIN rail mounting for flexible cabinet installation
• Designed for industrial vibration and condition monitoring applications
• High reliability for continuous operation
• Compatible with Rockwell Automation XM monitoring systems

Applications

• Industrial condition monitoring systems
• Motor vibration monitoring
• Rotating machinery protection
• Pump and compressor monitoring
• Factory automation equipment
• Process control systems
• Predictive maintenance systems

Notes

• Confirm compatibility with the specific XM module before installation
• Check wiring requirements and power supply specifications
• Avoid electrostatic discharge when handling the module
• Ensure proper DIN rail mounting and grounding
• Disconnect power before replacement or maintenance
