Allen-Bradley 1444-DYN-RPC-SCW-01 Dynamic Measurement Module Connector Set

Product Description

Allen-Bradley 1444-DYN-RPC-SCW-01 is a Dynamix™ 1444 Series removable screw clamp connector set designed for the 1444-DYN04-01RA Dynamic Measurement Module. It provides reliable field wiring connections for vibration monitoring and machine condition monitoring systems.

Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 1444-DYN-RPC-SCW-01
• Series: Dynamix 1444
• Product Type: Removable Plug Connector Set
• Compatible Module: 1444-DYN04-01RA Dynamic Measurement Module
• Connection Type: Screw Clamp Terminal
• Number of Positions: 16 Position
• Rated Current: 8 A
• Rated Voltage: 160 V
• Wire Size: 16 AWG
• Pitch: 3.81 mm
• Mounting Type: Pluggable
• Terminal Color: Grey
• Temperature Rating: Up to 115°C
• Application: Vibration and condition monitoring wiring connection

Advantages & Features

• Provides secure signal connection for Dynamix monitoring systems
• Screw clamp design ensures stable field wiring
• Removable connector structure simplifies installation and maintenance
• Reduces wiring replacement time during module servicing
• Designed specifically for 1444-DYN04-01RA modules
• Supports industrial vibration monitoring applications

Applications

• Machine vibration monitoring systems
• Motor condition monitoring
• Pump and compressor monitoring
• Gearbox fault detection
• Rotating equipment protection
• Predictive maintenance systems
• Industrial automation equipment

Notes

• Must be used with compatible 1444-DYN04-01RA Dynamic Measurement Module
• Check terminal wiring and sensor connections before installation
• Do not exceed rated voltage and current
• Ensure proper tightening of screw terminals
• Disconnect power before replacement or maintenance
