A-B 1411-2DRL-101 Current Transformer

Product Overview

The Allen-Bradley 1411-2DRL-101 is a Bulletin 1411 solid-core current transformer designed to measure AC current in industrial power monitoring and control systems. It converts a primary current of up to 100 A into a proportional 5 A secondary current for compatible meters, protective relays, and PowerMonitor devices.

Key Technical Specifications

Parameter	Specification
Brand	Allen-Bradley (A-B)
Model	1411-2DRL-101
Product Type	Current Transformer (CT)
Product Family	Bulletin 1411
Current Ratio	100:5 A
Rated Primary Current	100 A
Rated Secondary Current	5 A
Primary Voltage Rating	600 V line-to-line AC
Core Type	Solid core
Shape	Round
Window Diameter	1 inch (25.4 mm)
Accuracy	±1% at 60 Hz
Secondary Burden	5 VA at 60 Hz
Secondary Connection	Screw terminals
Country of Origin	United States

Features & Advantages

Accurate current measurement: Provides a 100:5 A current transformation ratio.
Solid-core construction: Designed for installation over a conductor or busbar.
Compact round window: Features a 1-inch opening for compatible conductors.
Power monitoring compatibility: Suitable for use with compatible meters, transducers, relays, and PowerMonitor products.
Industrial design: Supports electrical monitoring in industrial power systems.

Typical Applications

Industrial power monitoring
Electrical distribution panels
PowerMonitor systems
Current measurement and metering
Protective relay and transducer applications

Important Notes

This is a current transformer, not a voltage transformer or power supply.
Confirm the current ratio, window size, and secondary burden requirements before ordering.
Safety warning: Never energize the primary circuit while the secondary is open. Connect the specified burden or short-circuit the secondary according to the manufacturer's instructions before energizing. Installation should be performed by a qualified electrician.
