A-B 1411-180RL-301 Power Monitor

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• • • • • • • • • • • • • •

                            •

                            • Product Overview

                              The Allen-Bradley 1411-180RL-301 is a solid-core current transformer from the Bulletin 1411 series. It is designed to measure AC current in industrial electrical distribution and power monitoring systems. It converts a high primary current into a standardized 5 A secondary signal for use with power meters, monitoring equipment, and protective devices.



                              US+1



                              Technical Specifications

                              Parameter	Specification
                              Brand	Allen-Bradley (A-B)
                              Model	1411-180RL-301
                              Product Series	Bulletin 1411
                              Product Type	Current Transformer (CT)
                              CT Model	180RL
                              Current Ratio	300:5 A
                              Primary Rated Current	300 A
                              Secondary Rated Current	5 A
                              Accuracy	3%
                              Rated Burden	25 VA
                              Inner Diameter	2.5 inches
                              Core Type	Solid Core, Single Piece
                              Shape	Round
                              Secondary Connection	Screw Terminals
                              Metering Voltage	Up to 600 V AC line-to-line
                              Thermal Rating Factor	1.33 at 30°C
                              Mounting	Snap Mounting
                              Country of Origin	United States



                              US+1

                              Key Features

                              • 300:5 A current transformation ratio.

                              • Solid-core construction for reliable current measurement.

                              • 2.5-inch circular opening for conductor installation.

                              • 25 VA rated secondary burden.

                              • Screw-terminal secondary connections.

                              • Designed for industrial power monitoring applications.

                              • Suitable for integration with compatible metering equipment.

                              Typical Applications

                              • Industrial power monitoring systems

                              • Electrical distribution panels

                              • AC current measurement

                              • Energy management systems

                              • Power metering equipment

                              • Industrial electrical monitoring and control

                              Installation Notes

                              • Verify the 300:5 A current ratio before installation.

                              • Ensure the primary conductor fits through the 2.5-inch opening.

                              • Observe the correct polarity markings (H1/X1).

                              • Connect the secondary circuit according to the manufacturer's wiring instructions.

                              • Never leave the CT secondary circuit open while primary current is flowing.

                              • Installation should be performed by qualified electrical personnel.
