A-B 1326AB-B530E-21-K5 Servo Motor

Product Overview
The Allen-Bradley 1326AB-B530E-21-K5 is a 1326AB Torque Plus Series, three-phase brushless AC permanent-magnet servo motor designed for high-performance motion-control applications. It uses resolver-based feedback and includes a 24 VDC holding brake.

Technical Specifications

• Model: 1326AB-B530E-21-K5
• Series: 1326AB Torque Plus
• Type: AC Servo Motor
• Motor Type: Brushless, permanent-magnet synchronous
• Rated Voltage: 460/380 VAC
• Rated Speed: 3000 rpm @ 460 VAC / 2500 rpm @ 380 VAC
• Rated Output: 4.2 kW
• Rated Torque: 18 N·m
• Peak Stall Torque: Up to 54.2 N·m
• Frame Diameter: 149 mm
• Feedback: Resolver-based
• Brake: 13.6 N·m holding brake, 24 VDC coil
• Mounting/Shaft: IEC metric flange with keyway
• Motor Weight: Approx. 34.5 kg

Advantages & Features

• High-performance AC servo motor for precise motion control
• Permanent-magnet rotor provides fast servo response
• Brushless construction for reliable operation
• Resolver feedback provides position, velocity, and commutation feedback
• Integrated holding brake for load holding and safety
• Suitable for continuous-duty servo applications

Applications

• Industrial automation
• Robotics and machine tools
• Packaging machinery
• Material handling
• Manufacturing equipment
• High-performance motion-control systems
