A-B 104-C09D22 Contactor

104-C09D22
104-C09D22

A-B 104-C09D22 Contactor

A-B 104-C09D22 Contactor

  • Item NO.:

    104-C09D22

  • Payment:

    T/T

  • Price:

    $1000

  • Product Origin:

    USA

  • Color:

    NEW

  • Product weight:

    0.01KG

  • Lead Time:

    In stock
Inquire Now

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us

                                                                                                                                                                                                                                                                          •

                                                                                                                                                                                                                                                                          • A-B 104-C09D22 Reversing Contactor

                                                                                                                                                                                                                                                                            The Allen-Bradley 104-C09D22 is a Bulletin 104-C IEC reversing contactor rated at 9 A AC-3. It has a 110 VAC coil at 50 Hz / 120 VAC at 60 Hz, screw terminals, and 1 NO + 1 NC auxiliary contacts.

                                                                                                                                                                                                                                                                            Specification Details
                                                                                                                                                                                                                                                                            Brand Allen-Bradley / Rockwell Automation
                                                                                                                                                                                                                                                                            Model 104-C09D22
                                                                                                                                                                                                                                                                            Product Type IEC Reversing Contactor
                                                                                                                                                                                                                                                                            Series Bulletin 104-C
                                                                                                                                                                                                                                                                            Rated Operational Current 9 A AC-3
                                                                                                                                                                                                                                                                            Rated Operational Voltage Up to 690 VAC
                                                                                                                                                                                                                                                                            Coil Voltage 110 VAC @ 50 Hz / 120 VAC @ 60 Hz
                                                                                                                                                                                                                                                                            Coil Type AC
                                                                                                                                                                                                                                                                            Main Contacts 3 Power Poles
                                                                                                                                                                                                                                                                            Auxiliary Contacts 1 NO + 1 NC
                                                                                                                                                                                                                                                                            Motor Rating 4 kW @ 400/415 VAC, 50 Hz
                                                                                                                                                                                                                                                                            Motor Rating 5 HP @ 460 V / 7.5 HP @ 575 V, 60 Hz
                                                                                                                                                                                                                                                                            Utilization Category AC-2 / AC-3 / AC-4
                                                                                                                                                                                                                                                                            Terminal Type Screw Terminals
                                                                                                                                                                                                                                                                            Coil Termination Line Side
                                                                                                                                                                                                                                                                            Mounting Panel Mount / 35 mm DIN Rail
                                                                                                                                                                                                                                                                            Rated Insulation Voltage 690 V
                                                                                                                                                                                                                                                                            Impulse Withstand 6 kV
                                                                                                                                                                                                                                                                            Switching Frequency Max. 250 operations/hour
                                                                                                                                                                                                                                                                            Dimensions Approx. 98.6 × 80.77 × 84.63 mm
                                                                                                                                                                                                                                                                            Weight Approx. 1.27 kg

                                                                                                                                                                                                                                                                            Rockwell's official documentation identifies this specific catalog number as a 9 A reversing contactor with 1 NO + 1 NC auxiliary contacts.

                                                                                                                                                                                                                                                                            Advantages & Features

                                                                                                                                                                                                                                                                            • Reversing contactor designed for forward/reverse motor control.
                                                                                                                                                                                                                                                                            • 9 A AC-3 motor switching capacity.
                                                                                                                                                                                                                                                                            • 110/120 VAC 50/60 Hz coil.
                                                                                                                                                                                                                                                                            • Built-in 1 NO + 1 NC auxiliary contacts.
                                                                                                                                                                                                                                                                            • Suitable for motors up to 4 kW at 400/415 V.
                                                                                                                                                                                                                                                                            • Supports panel or 35 mm DIN-rail mounting.
                                                                                                                                                                                                                                                                            • Screw-terminal construction for secure industrial wiring.
                                                                                                                                                                                                                                                                            • Compatible with optional auxiliary contacts, surge suppressors, timers, interlocks, and overload relays.

                                                                                                                                                                                                                                                                            Typical Applications

                                                                                                                                                                                                                                                                            • Three-phase motor reversing
                                                                                                                                                                                                                                                                            • Industrial machinery
                                                                                                                                                                                                                                                                            • Conveyor systems
                                                                                                                                                                                                                                                                            • Material handling equipment
                                                                                                                                                                                                                                                                            • Machine tools
                                                                                                                                                                                                                                                                            • Pumps and fans
                                                                                                                                                                                                                                                                            • Factory automation
                                                                                                                                                                                                                                                                          •

The structure and details of the product：
