Allen‑Bradley 100-C72KD00 IEC Power Contactor

Product Overview

Model Code Breakdown

• 100-C: Standard IEC AC contactor family
• 72: Rated AC-3 motor current 72A
• K: 110V AC coil (50/60Hz)
• D: Screw-type power terminals
• 00: Zero auxiliary contacts (no NO/NC auxiliary built-in)

Core Electrical Specifications

Main Power Circuit

• Poles: 3 main NO power poles (L1/L2/L3 input, T1/T2/T3 output)
• AC-3 motor rating: 72A; Power capacity:
  • 230V: 22kW
  • 400/415V: 40kW
  • 500V: 45kW
  • 690V: 40kW
• AC-1 resistive load: 100A max @690VAC
• Max operational voltage: 690V AC
• Short-circuit withstand: 10kA @600V (with matched short-circuit protection)
• Impulse withstand voltage Uimp: 8kV

Coil Control Circuit

• Coil voltage: 110V AC 50/60Hz
• Coil termination: Line-side coil wiring, reversible coil terminals
• Drop-out delay: 18~23ms, stable anti-bounce performance
• Low holding power consumption, less coil heat generation

Wiring & Terminals

• Terminal type: Screw clamping terminals
• Wire range: 14–1 AWG copper wire (2.5–16mm²)
• Torque spec: 1.8–2.2 N·m for power terminals

Mechanical & Environmental

• Mounting: Standard 35mm DIN rail or direct panel surface mounting
• Dimension: W45 × H81 × D86.5 mm
• Weight: ~1.43kg
• Operating temperature: -25℃ ~ +60℃
• Protection grade: IP20 finger-safe housing for indoor cabinet use
• Vibration/shock: Compliant with IEC 60068 industrial standards

Certifications

Main Functions

1. Three-phase Motor On/Off Switching



   Carry rated motor starting and running current, control fans, pumps, conveyors, compressors and other AC induction motors; form complete motor starter combination with AB 193/592 thermal overload relays.
2. Heavy Inductive Load Control



   Suitable for switching large heaters, transformers, resistance furnaces under AC-1 resistive load mode up to 100A continuous current.
3. Expandable Auxiliary Signal Logic



   No built-in auxiliary contacts; install front/side-mounted auxiliary contact blocks (100-CAX series) to add NO/NC auxiliary contacts for PLC feedback, interlock and alarm signals.
4. Stable Anti-arc & Long Service Life



   Silver alloy main contacts suppress switching arc erosion; optimized magnetic arc extinguishing structure extends contact lifespan for frequent start-stop cycles.
5. Reversible Coil Wiring Design



   Coil terminals support wiring from line or load side, flexible cabinet wiring layout without extra wire rerouting.
6. Finger-Safe Safety Housing



   Fully shrouded power terminals prevent accidental electric shock during maintenance, meeting global machine safety requirements.

Key Advantages

• Compact narrow body saves cabinet space compared to equivalent competitors
• Wide temperature range (-25℃ ~ +60℃) fits high-temperature power rooms and cold workshop environments
• Low power consumption AC coil reduces cabinet heat accumulation
• Reversible coil terminals simplify wiring engineering
• Modular auxiliary contact expansion, flexible to match interlock logic demands
• Standard DIN rail mounting, quick installation and replacement
• Global multi-national certifications, applicable for export machinery and overseas MCC projects
• Perfect compatibility with Rockwell PLC, overload relays and motor control center assemblies

Typical Applications

• 40kW class three-phase fan, water pump and air compressor motor starters
• Packaging, injection molding, metal processing machine main motor control
• Factory automation conveyor and elevator auxiliary motor MCC panels
• HVAC central air conditioning heavy-duty fan control cabinets
• Marine, mining and process industry medium-power motor control circuits
• Heating furnace, transformer and large resistive load switching control
