A-B 100-C23KF01 IEC Contactor

Allen-Bradley 100-C23KF01 IEC Contactor





The Allen-Bradley 100-C23KF01 is a 3-pole IEC power contactor used for motor switching and industrial load control. It is part of the Allen-Bradley 100-C series motor control components, widely used in control panels for motors, pumps, compressors, and general power switching.

Key Specifications

• Model: 100-C23KF01
• Brand: Allen-Bradley (Rockwell Automation)
• Series: 100-C IEC Contactor
• Rated Current: 23 A (AC-3 motor duty)
• Main Poles: 3P (3 power poles)
• Coil Voltage: 230V AC (50/60 Hz)
• Auxiliary Contacts: 0 NO + 1 NC
• Mounting: DIN rail / panel mount
• Connection Type: Screw terminals
• Rated Power:
  • Up to 11 kW @ 400V AC (typical IEC rating)
• Standard Compliance:
  • IEC / EN 60947-4-1

(verified spec from Rockwell product data)

What it does (simple explanation)

Power Supply
↓
100-C23KF01 Contactor (coil energized)
↓
Motor / Load ON or OFF

When the coil is energized (230V AC):

• Contacts close → power flows → motor runs
  When coil is de-energized:
• Contacts open → motor stops

So it works like an electrically controlled heavy-duty switch.

Main Functions

• Switches 3-phase motors ON/OFF
• Controls pumps, fans, compressors
• Works with PLC outputs or pushbutton stations
• Provides auxiliary contact feedback (1NC)
• Used in motor starter assemblies (with overload relay)

Key Features

• Compact IEC design (DIN rail mount)
• High reliability for motor switching
• Built-in auxiliary contact for control feedback
• Low coil power consumption
• Compatible with overload relays and accessories
• Suitable for industrial control panels

Applications

• Motor control centers (MCC)
• HVAC systems (fans, compressors)
• Industrial pumps
• Conveyor systems
• Machinery power switching
• Automation control cabinets
