Allen‑Bradley 100-C09A10 – IEC 3-Pole Motor Contactor

Specifications

• Main Poles: 3 Normally Open (3NO) main power poles
• Built-in Auxiliary Contact: 1NO auxiliary contact
• AC-3 Rated Current: 9 A
• Max Rated Operational Voltage: 690 VAC
• Coil Voltage: 120 VAC 50/60 Hz
• AC-3 Motor Power Ratings:
  • 230V: 2.2 kW
  • 400/415V: 4 kW
  • 690V: 4 kW
• Wiring Terminals: Screw terminals, wire range 14–22 AWG
• Coil Power: Inrush ~60 VA; Holding ~6 VA
• Mechanical Endurance: 10,000,000 operations
• Electrical Endurance (400V AC-3): 1,500,000 operations
• Utilization Category: AC-3 (AC squirrel-cage motor switching)
• Mounting: Standard 35 mm DIN rail or direct panel mounting
• Operating Temperature: -25 °C to +60 °C
• Protection Class: IP2X finger-safe terminals
• Dimensions: 45 × 45 × 86.5 mm
• Weight: Approx. 0.26 kg
• Certifications: UL/cULus, CE, CSA, IEC 60947 compliant

Key Features

• Compact miniature size for small control cabinets
• Integrated 1NO auxiliary contact for status feedback logic
• Finger-safe terminal covers to prevent accidental electric shock
• Compatible with 193 series overload relays to build full motor starters
• Supports add-on auxiliary contacts, mechanical interlocks and coil surge suppressors
• Low holding power coil reduces cabinet heat generation
• Flame-retardant plastic housing with anti-vibration internal structure
• Wide range of matching accessories shared across the whole 100-C contactor family

Applications

• Small three-phase motor control: fans, pumps, small conveyors, packaging equipment
• Machine tool auxiliary drives, conveyor rollers, small valve actuators
• PLC-controlled load switching for low-power industrial equipment
• Combined with thermal overload relays for complete motor overload protection
