Weintek cMT2166X Human Machine Interface (HMI)





Product Overview

The Weintek cMT2166X is a 15.6-inch high-performance industrial HMI (cMT X Series) designed for modern machine visualization, remote monitoring, and multi-client access applications.

It is part of Weintek’s next-generation cMT (cloud-based HMI) platform, supporting multi-user access, web visualization, and advanced industrial communication protocols.

Key Specifications

• Brand: Weintek
• Model: cMT2166X
• Series: cMT X Series (Cloud HMI)
• Display: 15.6" WVA widescreen LCD
• Resolution: 1920 × 1080 (Full HD)
• Touch Type: Capacitive touchscreen (multi-touch, glass surface)
• CPU: Quad-core Cortex-A17 (high-performance industrial processor)
• RAM: 1 GB
• Flash: 4 GB storage
• Power Supply: 24 VDC ±20%
• Interfaces:
  • 1 × Ethernet (10/100 Mbps)
  • 1 × USB 2.0 Host
  • COM1 / COM3 RS-232 / RS-485 (selectable)
• Protection: IP66 / NEMA4 front panel
• Software: EasyBuilder Pro + cMT Viewer + EasyAccess 2.0

Key Features

• High-resolution Full HD industrial HMI (1920×1080)
• Multi-client architecture (mobile / PC / tablet access)
• Built-in VNC / web remote monitoring
• Supports MQTT / OPC UA (IIoT ready)
• Strong PLC compatibility (Siemens, AB, Mitsubishi, Omron, etc.)
• Edge computing + cloud connectivity (cMT platform)
• Capacitive glass touchscreen (modern UI experience)

Advantages

• Much higher performance than traditional MT8000 series
• Supports remote monitoring without extra hardware
• Ideal for Industry 4.0 / IoT systems
• Smooth HMI graphics + fast response
• Easy integration with multiple PLC brands
• Strong expansion capability via cMT architecture

Applications

• Smart factory automation systems
• Packaging & production lines
• CNC machine HMI interface
• Remote monitoring SCADA terminals
• Pumping, HVAC, and process control systems
• OEM industrial equipment

Precautions

• Requires correct PLC communication driver setup
• Ethernet configuration must match PLC network
• cMT system features (remote access / MQTT) may require license or setup
• Capacitive screen requires clean/dry operation environment
• Not designed for heavy vibration without proper mounting
• Ensure firmware consistency for cloud features
