TEMPERATURE XMTD-5000 Temperature Transmitter Product Information

Model: XMTD-5000
Product Type: Intelligent Temperature Transmitter / Temperature Controller
Application: Temperature measurement, monitoring, and automatic control in industrial processes

Technical Specifications

• Product Type: Digital Intelligent Temperature Transmitter / Controller
• Display Type: Digital LED display
• Input Signals:
  • Thermocouple: K, E, J, S, B
  • RTD: Pt100, Cu50
  • Linear signals: 0–10 mA, 4–20 mA, 0–5 V, 1–5 V (depending on configuration)
• Measurement Accuracy: ≤ ±0.5% F.S ±1 digit
• Resolution: 0.1 °C / 1 °C
• Sampling Period: Approx. 0.5 s
• Control Methods:
  • ON/OFF control
  • PID automatic control
  • SSR voltage control
• Alarm Output: Relay alarm output (depending on configuration)
• Power Supply: AC 220 V (standard models)
• Communication: RS485 / RS232 communication available on selected versions
• Operating Temperature: 0…50 °C
• Installation: Panel mounting
• Dimensions: 72 × 72 mm panel size (XMTD type)
• Panel Cutout: Approx. 68 × 68 mm

Advantages & Features

• High Measurement Accuracy
  Provides stable and precise temperature measurement for industrial control applications.
• Multiple Sensor Compatibility
  Supports various thermocouples, RTD sensors, and analog input signals for flexible system integration.
• Intelligent PID Control
  Automatically adjusts output parameters to improve temperature control accuracy and stability.
• Fast Response Performance
  Short sampling cycle enables rapid response to temperature changes.
• Strong Anti-Interference Capability
  Designed for reliable operation in industrial environments.
• Easy Installation and Operation
  Compact panel mounting design with digital display for convenient monitoring.
• Wide Industrial Application Range
  Suitable for heating, processing, and automation equipment.

Applications

• Industrial heating equipment
• Plastic processing machinery
• Packaging machines
• Food processing equipment
• Chemical processing systems
• Furnace and oven temperature control
• HVAC temperature monitoring
• Manufacturing production lines
• Process automation systems

Precautions

• Confirm the input sensor type before installation.
• Select the correct thermocouple compensation cable or RTD wiring method.
• Ensure the power supply voltage matches the device specification.
• Avoid installation in environments with strong vibration, moisture, or excessive electromagnetic interference.
• Set PID parameters correctly before operation.
• Check alarm limits and output settings before commissioning.
• Installation and maintenance should be performed by qualified personnel.
