                    • TELEMECANIQUE XUX5ARCNT16 Photoelectric Sensor

                      The TELEMECANIQUE XUX5ARCNT16 is a XUX series diffuse-reflective photoelectric sensor with an infrared emitter, relay output, and adjustable sensitivity. It operates on 24–240 V AC/DC and has a nominal sensing distance of 2.1 m.

                      Technical Specifications

                      Specification	Details
                      Brand	Telemecanique Sensors / Schneider Electric
                      Model	XUX5ARCNT16
                      Product Type	Photoelectric Sensor
                      Series	XU / XUX
                      Detection Method	Diffuse Reflective
                      Light Source	Infrared
                      Sensing Distance	2.1 m
                      Supply Voltage	24–240 V AC/DC
                      Output Type	Relay
                      Output Contacts	1 C/O (NO/NC)
                      Switching Capacity	3 A at 250 V
                      Switching Frequency	20 Hz
                      Connection	Screw-Clamp Terminals
                      Wiring	5-wire
                      Cable Entry	M16 × 1.5
                      Sensitivity	Adjustable
                      Housing Material	PBT
                      Lens Material	PMMA
                      Protection Rating	IP65 / IP67
                      Operating Temperature	-25°C to +55°C
                      Dimensions	Approx. 92 × 71 mm



                      Advantages & Features

                      • Diffuse-reflective detection without a separate reflector.
                      • 2.1 m nominal sensing distance.
                      • Wide 24–240 V AC/DC supply range.
                      • Relay output with NO/NC changeover contact.
                      • Adjustable sensitivity for different target objects.
                      • Compact industrial housing.
                      • IP67 protection for demanding industrial environments.
                      • Yellow output-status LED and green power LED.

                      Typical Applications

                      • Conveyor systems
                      • Packaging machinery
                      • Material handling
                      • Object detection
                      • Industrial automation
                      • Counting and positioning
                      • Machine presence detection

                      Installation Notes

                      • Align the sensor toward the target and adjust sensitivity according to the application.
                      • Avoid strong external light sources directly entering the sensing lens.
                      • Do not exceed the 3 A / 250 V relay contact rating.
                      • Ensure proper cable gland installation to maintain the specified IP protection.
