TELEMECANIQUE XUB9BPXNM12 Photoelectric Sensor
Item NO.:
XUB9BPXNM12Payment:
T/TPrice:
$650Product Origin:
JapanColor:
NEWProduct weight:
0.21KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
Brand: Telemecanique Sensors
Model: XUB9BPXNM12
Product Name: XUB Polarised Reflex Photoelectric Sensor
Product Type: Polarised Reflex Photoelectric Sensor
Series: XUB / XU General Purpose
| Key Technical Specification | Details |
|---|---|
| Product Type | Photoelectric Sensor |
| Detection System | Polarised Reflex |
| Sensing Range | 0.05–7 m |
| Nominal Sensing Distance | 5 m with XUZC50 reflector |
| Emission | Red LED, Polarised Reflex |
| Sensor Design | Cylindrical M18 |
| Housing Material | Metal |
| Supply Voltage | 12–24 V DC |
| Output Type | PNP |
| Output Function | 1 NO or 1 NC, programmable |
| Switching Frequency | 1000 Hz |
| Response Time | 0.5 ms |
| Sensitivity Adjustment | Potentiometer |
| Connection | 4-Pin M12 Male Connector |
| Wiring | 4-Wire |
| Output Current | ≤100 mA |
| Output Protection | Overload and Short-Circuit Protection |
| Lens Material | PMMA |
| Protection Rating | IP65 / IP67 / IP69K |
| Line of Sight | Axial |
| Status Indicators | Green Power/Stability LED + Orange Output LED |
| Operating Temperature | Approx. -30 to +55°C |
| Weight | Approx. 0.04 kg |
Polarised-reflex photoelectric detection
Compact M18 cylindrical metal housing
PNP output with programmable NO/NC function
Fast 0.5 ms response time
Up to 7 m sensing range
4-pin M12 industrial connector
IP65, IP67 and IP69K protection
Sensitivity adjustment via potentiometer
Overload and short-circuit protected output
Conveyor and material handling systems
Packaging machinery
Object detection
Product counting
Position monitoring
Industrial automation
Production-line sensing
A suitable reflector is required for polarised-reflex operation; Schneider/Telemecanique specifies XUZC50 for the nominal 5 m range.
Verify the 12–24 V DC supply and PNP wiring before installation.
Align the sensor and reflector correctly.
Keep the optical surfaces clean to maintain reliable detection.
Confirm the required sensing distance and reflector before replacement.
