Telemecanique XSD-A600519 Sensor

Telemecanique XSD-A600519 Inductive Proximity Sensor (XSD Series)



The Telemecanique XSD-A600519 is an industrial inductive proximity sensor, used to detect metal objects without physical contact. It belongs to the Telemecanique Sensors XS/XSD series.

Product Information

• Brand: Telemecanique (Schneider Electric)
• Series: XS / XSD inductive sensors
• Model: XSD-A600519
• Type: Inductive proximity sensor
• Sensing method: Non-contact metal detection
• Housing size: 80 × 80 × 40 mm
• Sensing distance: up to ~60 mm
• Supply voltage: 24–240 VAC (2-wire system)
• Output: NO / NC programmable (discrete output)
• Material: Plastic housing
• Protection rating: IP67
• Mounting: Non-flush type
• Connection: Screw terminal / cable entry (Pg13.5)

What it actually is

This is a sensor, not a control module.

It is used to:

• Detect presence of metal objects
• Trigger PLC inputs or relay signals
• Provide position / presence feedback in machines

It does NOT:

• Control machines ❌
• Act as PLC or module ❌
• Process logic ❌

System Role (Simple)

Metal target moves near sensor
→ XSD-A600519 detects it
→ sends ON/OFF signal
→ PLC / relay / controller responds

So it acts like a “metal detection switch (non-contact).”

Key Features

• Non-contact detection (no wear)
• Large sensing distance (up to 60 mm)
• Wide AC voltage range (24–240V)
• Industrial rugged housing (80×80×40)
• IP67 protection (dust/water resistant)
• 2-wire AC output system
• Programmable NO/NC output

Typical Applications

• Metal part detection on conveyor lines
• Machine position detection
• Factory automation systems
• Packaging machinery
• Safety interlock detection
• Material handling systems

Advantages

• No mechanical wear (non-contact sensing)
• High durability in harsh environments
• Simple wiring (2-wire AC type)
• Long sensing range compared to standard sensors
• Reliable industrial detection

Important Notes

• Not a PLC ❌
• Not a relay ❌
• Not a control module ❌
• It is a proximity sensor (input device) ✔
• Requires metal target for detection (does not detect plastic/liquid directly)

Precautions

• Must use correct AC supply (24–240V range)
• Do not exceed switching frequency (~10 Hz)
• Install within correct sensing distance range
• Avoid strong electromagnetic interference
• Ensure proper mounting orientation (non-flush type)
