TELEMECANIQUE XCSDMP700L01M12 Safety Switch
Item NO.:
XCSDMP700L01M12Payment:
T/TPrice:
$650Product Origin:
JapanColor:
NEWProduct weight:
0.21KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
Brand: Telemecanique Sensors
Model: XCSDMP700L01M12
Product Name: Coded Magnetic Safety Switch
Product Type: Safety Coded Magnetic Switch
Series: Preventa XCS
| Key Technical Specification | Details |
|---|---|
| Product Type | Coded Magnetic Safety Switch |
| Series | XCS |
| Component | XCSDMP |
| Design | Rectangular, Standard |
| Contact Configuration | 2 NC + 1 NO |
| Contact Operation | 1 NC Staggered |
| Rated Operational Voltage | 24 V DC |
| Rated Insulation Voltage | 100 V DC |
| Rated Operational Current | 100 mA |
| Switching Capacity | 0.1–100 mA |
| Connection | M12 Connector |
| Cable Length | 0.15 m |
| Number of Poles | 3 |
| Assured Operating Distance | 8 mm |
| Assured Tripping Distance | 20 mm |
| Switching Frequency | 150 Hz |
| Body Material | Thermoplastic PBT |
| Contact Material | Rhodium |
| Protection Rating | IP67 |
| Dimensions | 88 × 25 × 13 mm |
| Short-Circuit Protection | 500 mA external gG/gl fuse |
| Safety Level | Up to Category 4 / PL e / SIL 3 with appropriate monitoring |
| Electrical Shock Protection | Class II |
| Mounting / Approach | 3 approach directions |
Coded magnetic safety switch for machine guarding
Compact rectangular design
2 NC + 1 NO contact configuration
M12 connection with 0.15 m flying lead
IP67 protection for industrial environments
Assured operating distance of 8 mm
Can achieve Category 4, PL e and SIL 3 when correctly integrated with an appropriate safety monitoring system
Suitable for non-contact safety monitoring
Safety guard door monitoring
Machine safety systems
Protective door monitoring
Industrial automation equipment
Production machinery
Safety-related control systems
This is a coded magnetic safety switch, not a standard mechanical limit switch.
Use with an appropriate safety monitoring system to achieve the specified safety level.
Verify the 24 V DC system voltage and maximum 100 mA switching current.
Use the specified external 500 mA gG/gl fuse protection.
Maintain the specified operating and tripping distances during installation.
Confirm M12 connector and cable compatibility before installation.
